Oce Repro Desk User Manual page 391

[268] Scan into job dialog box
If required, define the file template.
4
Click 'OK'.
5
The scan job is saved. The 'Scan' button in the toolbar changes to a 'Stop Scan'
button.
[269] Stop Scan button
An empty job window appears.
Scan the original on the Océ TDS800 scanner.
6
The scanned original appears as a file in the job window.
You can now scan more originals or save and close the job.
If 'Rename Scan Files' is checked, Repro Desk renames the incoming
Note:
scans according to the template. Otherwise, the naming convention on the PLC
is used.
Scan into a new job
Click the 'Scan' button in the toolbar.
1
When no job or queue is active, a new job window with a new job name
appears.
In front of the new job window, the following dialog box appears.
[270] Scan into a new job dialog box
If required, define the job name, destination and file template.
2
Scan TDS 391
