Hp-Gl/2 Hp-Rtl Output - Oce Repro Desk User Manual

HP-GL/2 HP-RTL output

The HP-GL printer (for example, Océ 5200) can be installed in two ways:
As local printer, connected to one of the parallel ports (for example, LPT1)
of the Server PC.
As remote printer, connected to a network.
If the HP-GL printer is installed as remote printer, you must install a
Note:
driver on the Océ Repro Desk PC. You can use any Windows driver for this
purpose, since it is only used to make the connection to the HP-GL printer. Océ
Repro Desk will provide the actual driver functionality.
It is also possible to save the output as HP-GL/2 HP-RTL file in a specified
directory, or to send the output to a queue.
Print on HP-GL printer or save as HP-GL/2/HP-RTL file
Open a job window, containing the job you want to print.
1
(see 'Print from a queue' on page 204).
2330
[117] Job Window
If required, you can change the file settings in the Job window (see chapter 9,
2
'Imaging properties' on page 123).
Select 'Print HP-GL/2/HP-RTL' in the 'Print' Quick menu.
3
3724-144
[118] Selecting 'Print HP-GL/2/HP-RTL' in the 'Print' Quick menu
Printing 221
