Pen settings

A pen is used to control the appearance of lines drawn by a customer.
Pens are only applicable for Vector files, so not on Raster files
Pen zero is used for Raster files and for Stamps (grayshading).
Océ Repro Desk can set pen weights (width), patterns, shapes, effects, and
colors. This allows you to customize the appearance of your customer's
drawings. Océ Repro Desk can create, save, and store an infinite number of
pen sets.
When a job is opened, Océ Repro Desk will apply a pen set called
STANDARD.PEN. This pen set is used for regular use. You can view the pen
settings using the Pen set icon on the button bar.
3680
The Pen settings window appears.
The STANDARD.PEN is installed at the time of installation of Océ Repro
Desk. Pen settings need to be customized only once. When you transmit your
jobs for printing, your personal settings will be applied to every job you send.
