Printer, such as length unit (metric or U.S.), weight unit (grams or pounds),
paper series (DIN, DIN Carto, 8.5 inch, 8.5 and 9 inch, or JISB), and the first
and second languages for the interface.
Folder, such as print orientation (portrait, landscape, or auto detect), folding
method (DIN, AFNOR, or Ericcson), Fold delivery (first fold exit, fold stack,
or belt 1), or reinforcement selected.
Packet, such as packet width, packet length, binding value, sheet length,
sheet width, or binding selected.
Key operator settings
where you can make a number of key operator settings and perform several
tests for the Océ Repro Desk Server.
You need the key operator password to get access to these settings. This
Note:
password is given to you by the Océ technician after installation.
The Key Operator Settings window contains the following four tabs:
Roll Drawers
Sheet Feeder
Transport and Folding
Other
From the Roll Drawers tab you can adapt the leading edge position of the
image related to the leading edge of the paper and you can modify the width
position of the image on the paper from the upper, middle or lower roll
drawers.

Adapt the leading edge position of the roll drawers

If you want to adapt the leading edge position of the roll drawers, and you
know which value you want to choose, you simply enter this value (in tenths
of millimeters) into the Enter value field and click on the Leading Edge
Position button. After confirmation, the leading edge position is set to the
specified value. If you do not know which value you want to enter you can take
the following procedure.
Adapt the leading edge position of the roll drawers
Make a basic test print from Roll 1 by clicking on the Test Print Basic button
1
on the 'Other' tab.
Take a ruler and measure the distance between the edge of the paper and the C
2
marker on the test print.
Print on an Océ 9600
The Key Operator option takes you to a sub menu
273
