Enlarging when scanning a standard size original
Press one of the zoom step buttons on the operator panel, just below the zoom
1
display, to change the zoom factor for your original by standard steps (A4 to
A3, A3 to A2, etc). This will result in a standard size scanned image.
If you want to change your zoom factor by non-standard steps, you
Note:
have to use the custom width and custom length settings.

Scanning originals with filing strip

You can adjust the original guide of the scanner to remove or add a filing strip
along the left hand side (in the feed direction, face-up). The left hand side can
be extended up to 20 mm or shortened up to 60 mm (0.78 to 2.36 inch).
[308] Example of adjusting the left hand side of an original
Scanning with removed or added filing strip along the left hand side
If you want to remove a filing strip, move the original guide to the left.
1
Scan 9800/9600
Left hand side
- 40 mm
Left hand side
+20 mm
