Folder (Océ 9700/9800) - Oce Repro Desk User Manual

If required, you can change the settings for the 'Gray Scale', 'Font Size' and
4
'Stamp Position'.
Click Apply.
5
Folder (Océ 9700/9800)
If the Océ 9700/9800 is equipped with a folder, you can specify folder settings.
You can save the folder settings in a configuration file, and recall them
whenever needed.
It is possible to specify the Folding options already when creating the job (see
'Folder' on page 132).
When creating the job, you can see in the viewer what part of the drawing will
be on top after folding (see 'View fold' on page 109).
Folder options
number of options. Depending on the configuration of the folder you are using,
you can specify the following options:
Don't fold: Output will not be folded.
Fold: Output will be folded without any options.
Fold & Punch: Output will be folded and punched (if puncher installed).
Fold & Reinforce: Output will be folded, and a reinforcement strip will be
added (if reinforcement unit is installed).
First fold Exit: Output will only be folded in one direction (first fold), and
then delivered in the First fold delivery tray.
To use Punching or Reinforcement, you must select one of the belts for
Note:
output delivery in the delivery settings only (see 'Delivery (Océ 9700/9800)'
on page 265).
Method
Ericsson or AFNOR.
Orientation
portrait orientation. If you select 'Automatic', the machine determines the
length of the drawing to obtain a good fold package, depending on the roll
width
Folding size
Print on Océ 9700 or Océ 9800
The folder of the Océ 9700/9800 can be equipped with a
You can specify one of the following folding methods: Standard,
If you select 'Portrait' as Orientation, the drawing should be in
You can specify the Folding width and Folding height yourself.
261
