Drawing size

This field displays the original size of the drawing.

Zoom

You can specify the zoom factor as follows:
Make an enlargement or reduction
Open the job with the desired drawings.
1
Click with the right mouse button on the Zoom field of the drawing you want
2
to change.
The Zoom drop-down menu appears.
Select the desired zoom setting:
3
One of the predefined zoom factors.
Fit Page: Zoom factor will be changed automatically to fit the specified

Paper Size.

50% Reduction or 200% Enlargement: The Paper Size will automatically
change to fit the drawing.
Select: The Imaging Properties window appears, to specify a custom zoom
factor.
Click outside the drop-down menu to remove it.
4
Click OK when the Imaging Properties window is activated
5
If you select either 50% reduction or 200% enlargement, the media
Note:
size will automatically change with the size of the drawing. For other zoom
settings, you must also change the paper size. If you wish to set a custom
percentage of zoom, choose Select from the menu.
Paper size
You can select from a variety of standard paper sizes to print on, or define
custom paper sizes.
Change the paper size
Open the job that contains the desired drawings.
1
Click with the right mouse button on the Paper Size field of the drawing you
2
want to change.
The paper size drop-down menu appears.
Handling jobs 79
