Control center

Another way to look at multiple machine support is shown in the illustration
below.
The customer prepares jobs on the Repro Desk Remote Client.
1
The files are transferred to the Job Printer site via LAN, FTP, modem, etc.
2
The Job Printer has a PC with Repro Desk Remote Client installed.
3
This PC asks at a hub.
Using a broadcasted queue the jobs can be sent from the hub to the printers.
4
For example, Océ TDS800 with PC running Océ Repro Desk Server 1.0 and
5
TDS800 Printer module.
For example, Océ 9600 with PC running Repro Desk 9600 Server.
6
HP-GL/2 files can be can be sent to an inkjet printer.
7
Such as the Océ 5200.
8
PostScript files can be sent to a PostScript printer.
9
Such as the Océ 3165 or a laser printer.
10
1
[222] Multiple machine support
346 Océ Repro Desk Server User Manual
