Stamp Options - Oce Repro Desk User Manual

If you want to add the new stamp to the current job, click OK.
5
The Stamp Properties window will disappear, and the stamp will automatically
be added to the current job (if any).
If you do not want to add the new stamp to the current job, click Cancel.
6
The Stamp Properties window will disappear, and you can add the stamp to a
job later on (see 'Add a stamp to a drawing' on page 154).
If you have modified the Repro Desk work order using the Work Order
7
Customizer, you will have different stamp elements available in the Stamping
Options list box.

Stamp options

The Stamp window contains following elements:
Preview window
rotation and spacing will affect your text.
Enter text window
plain text.
Stamping options
date, time, project and file name, page and set number to your label. This
information is directly linked to the file and the computer, so when you print
the stamp or label you have current date, time and file name etc. This
information is displayed as codes in the Enter Text window.
If you have selected the File Name option and the drawing is processed,
Note:
the original path of the drawing is displayed in the stamp. Otherwise it only
shows the filename without the path.
Font properties
you can change the type, size and style of the font. The current font settings are
displayed in the Font Sample field.
Character rotation field
orientation. Use the up arrow to rotate the text counter-clockwise and use the
down arrow to rotate the text clockwise.
Baseline rotation field
baseline counter-clockwise and use the down arrow to rotate the baseline
clockwise.
Define Stamps and Overlays
The Preview window displays how changes such as font,
The text used for the label is displayed in this window as
Mark the appropriate check box to add information such as
Click 'Choose Font' button to open the font dialogue box where
Rotates the letters and the baseline to change text
Rotates the baseline only. Use the up arrow to rotate the
151
