Scan with the Océ 9600
If you have an Océ 9600 scanner attached and you have the optional
Scan-to-File software installed on the server, you can scan drawings and save
them as files. These files can then be printed on the Océ 9600 printer to
produce a copy of the original drawing. Scanning is controlled through the
Scan Documents dialog box.
As drawings are scanned, a preview of the scan is available in the Océ 9600
Print Manager window.

Name and save scanned files

Repro Desk offers the following possibilities for scanning.
Scan to a queue
1
Scan into a new job
2
Scan into an existing, not saved job
3
Scan into a saved job.
4
Scan to a queue
Open a queue (see 'Opening a queue' on page 187) or activate an already
1
opened queue.
Click the 'Scan' button in the toolbar.
2
[278] Scan button
The following dialog box appears.
[279] Scan to queue dialog box
Click 'OK'.
3
A subdirectory of the queue is created corresponding to 'latest.num'. The
following dialog box appears, in which that subdirectory is the default.
Scan 9800/9600 401
