The area inside the frame is grayed out. Only the selected area of the drawing
will be printed.
You can undo this setting by selecting 'Crop Drawing Inside' in the Drawing
6
menu again.
Enlarge detail
With the Enlarge detail option you can select a part of the drawing to fit the
size of the selected paper.
Attention:
printed drawing (layout).
Creating a detail
Click the Detail button.
1
Move the mouse to the drawing.
2
Hold the left mouse button.
3
Move the mouse to create a frame of the required size.
4
Release the left mouse button.
5
The area inside the frame will be enlarged to fit the selected paper size.
To undo the enlargement click the Detail button again and select the
Note:
complete drawing.
Edit pen
With the Edit Pen option you can edit the pen settings. You can change the
thickness, the pattern, the effect of a particular pen in a drawing.
Editing pens
Click the Edit Pen button.
1
Move the mouse pointer to the pen line you want to change.
2
Click the left mouse button.
3
The Pen window of the selected pen appears.
112
Océ Repro Desk Server User Manual
Changes made with this feature will effect the drawing or the
