Enter the resulting value (in tenths of millimeters) in the Enter value field and
3
click on the Edge and marker "C" Roll 1 button.
The leading edge position is adapted automatically, based on the specified
value.
If an invalid value is entered, the following message is displayed:
Note:
'Value x is out of bounds. Range is from a to b. Default is c', where x is the
specified value, a the minimum value, b the maximum value, and c the
default value.

Modify the roll drawer width positions

If you want to modify the width positions of the upper (rolls 1 or 2), middle
(rolls 3 or 4) or lower (rolls 5 or 6) drawers, and you know which value you
want to choose, you simply enter this value (in tenths of millimeters) into the
Enter value field and click on the appropriate button. After confirmation, the
appropriate width position is set to the specified value. If you do not know
which value you want to enter you can take the following procedure.
Modify the roll drawer width positions
Make a basic test print from Roll 1 or 2 (for the upper drawer), Roll 3 or 4 (for
1
the middle drawer) or Roll 5 or 6 (for the lower drawer) by clicking on the Test
Print Basic button on the Other tab.
Take a ruler and measure the distance between the edge of the paper and the F
2
marker on the test print.
Enter the resulting value (in tenths of millimeters) in the Enter value field and
3
click on the appropriate Edge and marker "F" Roll x button, where x can be 1
(upper drawer), 3 (middle drawer) or 5 (lower drawer).
The appropriate width position is adapted automatically, based on the specified
value.
If an invalid value is entered, the following message is displayed: 'Value
Note:
x is out of bounds. Range is from a to b. Default is c', where x is the specified
value, a the minimum value, b the maximum value, and c the default value.
From the Sheet Feeder tab you can adapt the leading edge position of the image
related to the leading edge of the paper and you can modify the width position
of the image on the paper from the upper, middle or lower sheet feeders.
274 Océ Repro Desk User Manual
