The appropriate width position is adapted automatically, based on the specified
value.
If an invalid value is entered, the following message is displayed: 'Value
Note:
x is out of bounds. Range is from a to b. Default is c', where x is the specified
value, a the minimum value, b the maximum value, and c the default value.
From the 'Transport and Folding' tab you can adapt the leading edge position
of the image related to the leading edge of the paper fed through the manual
feed (this is the same as for the sheet feeders), modify the width position of the
image on the paper from the manual feed, correct the deviation of the sensor
used to measure the length of a sheet, specify the extra overlap you want in the
first fold of the folder and determine the number of copies that can be placed
on the output belt of the folder.
The leading edge and width positions are determined the same way as
Note:
with the sheet feeders. The only difference is that, in this case, the test print has
to be made from the manual feed.

Modify the static deviation

If you want to modify the deviation of the sensor used to measure the length of
a sheet, you can either enter the required value in the Enter Value field and
click on the Static Deviation button, or you can take the following procedure.
Modify the static deviation
Click on the Static Deviation Measured Length button to start the test.
1
A blank sheet is now produced.
Take a ruler and measure the length of the sheet.
2
Enter the result in the Key Operator Settings Test window (in tenths of
3
millimeters when the system prompts you to do this and click on OK.
The system now compares the specified length with the length measured by the
printer and automatically corrects the deviation.
To specify the extra overlap you want in the first fold of the folder and to
Note:
determine the number of copies that can be placed on the output belt of the
folder you simply enter a value in the Enter Value field (in tenths of millimeters
and number of copies respectively) and click on the appropriate button (Folder
1 Overlap or Folder Output Belt Capacity).
276 Océ Repro Desk User Manual
