SECTION 12 : MIDI REMOTE CONTROL

Overview

Program Changes

MIDI presets

MIDI presets Menu
MP01
Current MIDI
Preset
Euphonix CS3000/2000 Operation Manual
T
he CS3000/2000 contains many MIDI communication capabilities.
These features include control and automation of MIDI outboard FX
equipment, external control of the console from MIDI sequencers in both
studio and live applications and SnapShot linking between consoles in our
multi-operator film systems.
Additionally, several objects on the Mix Controller are now able to send and
receive MIDI continuous control data. Objects capable of sending data are
group master faders & mutes. Objects capable of receiving data include
channel & group master faders, channel mutes, pans & aux sends, Dyn filters,
all EQ parameters and all Cube controls including aux and pan.
MIDI program changes are set up easily using a series of SmartDisplay/
Assignment display menus. As with console Snapshots, there are fifty (50)
MIDI presets which you can use for example, to control outboard FX gear or
link to scene changes in lighting consoles via port 3 of the console's MIDI
interface box. Think of them as MIDI "snapshots".
There are only two pieces of information you need to know before you setup
and recall MIDI program changes:
1. What MIDI channel you want to use
2. What device specific program change you want to use
To access the MIDI Preset menu and assignment display, press the DSC
[Studio] key:
01:Ch1 – – –
F1 F2 F3
MIDI channel
& Name
MIDI Program
Change
Section 12: MIDI Remote Control
Ch 1
RCL
F4
Ch 2
Ch 3
Ch 4
Ch 5
Ch 6
Ch 7
Ch 8
Pg 1 Pg 1 Pg 2 Pg 2
Mon Mon Mon Mon
Select Select Cnfg Cnfg
1 — — — 9
2 — — — 10
3 — — — 11
4 — — — 12
5 — — — 13
— — —
6 14
7 — — — 15
8 — — — 16
Faders Faders Store Store
Pg 3 Pg 3 Pg 4 Pg 4
Preset Preset Studio Studio Macro Macro Snap Snap
Shot Shot
