Fast Access to
Group Control
DSC Master
Control Panel
Pass Grps Mtrs
Ctrl
nap System G

Deleting Groups

Delete an Individual
Group
Select group by
pressing a master
fader's block key
Euphonix CS3000/2000 Operation Manual
Press the [Grps] Dedicated key on the Master Control Panel to enter a "lim-
ited" Group mode menu, allowing you to access limited grouping functions.
This differs from the Group Select menu in 3 primary ways:
1. Entering Limited Group mode doesn't interrupt meters from tracking
audio.
2. Group Master options are available from this menu while automation is
running (when [Mix On] is lit).
3. It allows two basic group operations. You can turn groups on or off and
toggle MSTR/IND modes. Groups cannot be edited from this menu.
This menu is a quick and convenient way to access basic grouping features
(single-button access) while still being able to monitor audio levels on the
meters.
It is possible to delete individual groups as well as all groups.
Press [F4] (Grps) from the Main menu. Select the master of the group to be
deleted. Press the [Clr] key above the SpinKnob and confirm by pressing [F3].
Press the [Clr] key:
Pressing [F3] will delete the group; [F4] or [Esc] aborts this and leaves the
group intact. If the group master fader was not at 0.00dB, the level of the
slaves will jump back to their original levels, as will the master fader's under-
lying DCA audio level if it is a slave in the group.
Section 8: Grouping System & Fader Linking
Group Mode: ON
F1 F2 F3
Toggle group
system ON & OFF
Group Select: ON
F1 F2 F3
Slave Select:
F1 F2 F3
Sure? Yes
F1 F2 F3
MSTR
F4
Toggles Master/
Independent modes
MSTR
F4
MSTR
F4
[No]
F4
8 - 11
