Track Assign Keys

Transport Controls

Monitor Section

Euphonix CS3000/2000 Operation Manual
Rec
These keys are for future implementation. At this time the displays are used to
monitor MIDI timecode returning to the DSC. Note: this reader does not
display frames.
The Transport keys are used for MIDI Machine Control of compatible tape
transports such as the Tascam DA-88™ and the Alesis ADAT™.
Loc
These keys allow the user to control external machines that support MIDI
Machine Control protocol, as well as to control the automation without
external code using the console's VTM (Virtual Tape Machine). The MMC keys
support Play, Record, Stop, Forward, Rewind, Cycle, Shuttle, Locate to Cue,
Next Cue, Last Cue, and RollBack.
The Euphonix VTM is effectively an internal timecode generator. When the
DSC Mstr Ctrl and T/C Slave keys are off, then internal timecode can be
generated. See the Tutorial and Automation sections for additional details.
This section is for future implementation. Currently, all monitor facilities are
controlled via the Master Module.
1
2
4
6
8
Rec Rec
1
2
4
6
8
ComMic
Talk
Section 1: Introduction
Rec
Auto
Rec
1 - 21
