Assigning Midi Channels; Assigning Midi Channel Names; Sending Multiple Midi Program Changes; Linking Presets To Console Snapshots - Euphonix CS3000 Operation Manual

Assigning MIDI channel
Names
Sending Multiple MIDI
Program Changes
Setup
F1
File
F1
Linking Presets to
Console
SnapShots
Euphonix CS3000/2000 Operation Manual
Descriptive names may be assigned to any MIDI channels by pressing [F1] on
the QWERTY keyboard. The Assignable key display shows up to eight charac-
ters while the SmartDisplay menu shows the name's first three characters:
MP01
F1
After entering/modifying a MIDI preset, you can choose to send all of its
assigned program changes at once or each program change individually. To
send all MIDI program changes at once, press [F4] (RCL). To send individual
MIDI channel changes, press the left Assignable key adjacent to the MIDI
channel you wish to send.
Should you ever want to prevent the console from sending all configured
program changes, you can disable all outgoing console program change
activity. From the top-level menu press [F3], [F4] and then [F3]:
Snap System Grps
F2 F3 F4
F-Link GPI MIDI
F2 F3 F4
You can now disable all console MIDI program changes by pressing [F1]. [F3]
clears all MIDI assignments for the currently selected preset and [F4] allows
another way to name the currently selected MIDI channel.
SnapShot linking allows any configured MIDI preset to be recalled using the
console SnapShot recall system. This is a powerful feature allowing automa-
tion of an entire MIDI studio.
To link any of the fifty (50) MIDI presets to any of the fifty (50) console
SnapShots, press the DSC [SnapShot] key and select the Snapshot you want
to link to. Next, press the DSC [Studio] key to display the MIDI preset menu.
Once all parameters of the desired preset have been selected (midi preset,
Section 12: MIDI Remote Control
Reverb 1 PRG 31
2
Ch 2 — — —
01:Rev
F2 F3
In Out
F1 F2
Enabled
F1 F2
9
10
31 RCL
F4
Preset SS->SS
F3 F4
Clear Name
F3 F4
12 - 5
