Dedicated Keys

Selects Block Key
Attention mode
Fast, direct access
to Template modes.
Keys used to select Fader/
Pan/Mute and Aux ABCD
controls in the Punch and
Template menus.
Selects Trim Punch mode
directly
When lit, touch punch-in
from Assignable Moving
Fader is activated.
Routing Keys.
M1, M2, L1, L2, L3, L4 allow
fast source selection.
ST1, ST2, and DIR allow fast
access when assigning faders
to their sources.
Euphonix CS3000/2000 Operation Manual
The Routing keys in the lower left section are used to route signals through
the individual channels to various console buses. The All aux, All upper, and
All lower keys allow quick configuration of Punch and Template modes.
Others allow immediate access to automation modes such as Trim and Abso-
lute without the need to go through menus in the SmartDisplay. These modes
are covered in detail in the Automation section.
Selects Punch mode
during automation &
selects Punch menu
Attn
Set
Fader
A
Trim
Abs
Offset
M1
L1
L3
Pnch Tplt Auto
Iso Dyn Safe
Pan On
B C
ATO W in W out
MBR Move Glide
Rec
M2 DIR
L2 ST1
upper
L4 ST2
lower
Section 1: Introduction
Selects
Template
menu
Access Auto
SS
SnapShot
menu
D
Select Punch
Extension modes
directly.
These keys are
All for configuring
aux
groups of
controls. They
operate only in
All
Template and
Punch menus.
All
1 - 13
