Section 4: Tutorial
M1 M2 DIR
L1 L2 ST1
L3 L4 ST2
7 8 9
4 5 6
1 2 3
Mono Pan Center
Locked Mode

Mono mode

SIDE NOTE:
This mode is rarely used and
should not be confused with the
similarly displayed Mono
Independent mode.
4 - 34
Press the [*ST] key again to select MonoPan mode:
16AB->
Press the DSC [L4] key to directly assign the aux source routing:
16AB->
Press the DSC keypad [1] & [2] keys to directly assign the aux send to aux bus
1 & 2:
16AB->
Whenever a stereo linked mode is set, the aux A (C) pot becomes the pan
control and the aux B (D) pot becomes the level control. The aux send is now
ready for use.
This concludes Exercise 7.
Remember that direct access to any aux mute and pre/Post parameters is
always available from the top level Aux menu, simply by pressing any aux
send attention key.
There are some additional mono-in variations which bear mentioning at this
time. From the Aux Status menu, press [F3] to lock the pan control signal at
the center:
16AB->
An additional mode is accessible from this Level/Pan Mode menu. This Mono
mode sums all inputs and outputs, disables the upper control of the A/B and
C/D aux sends and is included here only for backward title compatibility with
earlier versions of software.
Press [F2] to select Mono mode:
16AB->
MnPan Ctr
F1 F2 F3
F1 F2 F3
BUS 1 2
F1 F2 F3
MnPan Ctr
F1 F2 F3
Mono - - -
F1 F2 F3
Euphonix CS3000/2000 Operation Manual
Ind?
F4
L4<-p. .
F4
F4
Ind?
F4
Ind?
F4
