Record
Rec
Shuttle/Jog
Previous/
Next Cue
Locate
Loc
RollBack/PreRoll
Auto
Euphonix CS3000/2000 Operation Manual
Sends MMC Record command. Only one-touch record is presently supported.
Pressing Play while recording will drop MMC device out of Record mode.
Enable/disable cycling. More about this later.
Cycle
When MMC is used to control an external tape machine, the SpinKnob can be
used as a shuttle/jog wheel to advance or rewind tape at variable speeds. The
Rewind and Forward buttons light to indicate direction of shuttle. The faster
the button blinks, the faster the shuttle speed selected. Pressing Stop or the
Shuttle button a second time will exit Shuttle mode.
Note: Many digital 8-track machines do not support frame-accurate remote
timecode tracking or jog control.
Used to move between consecutive cues in the Cue list when in Cue mode.
Will automatically locate MMC device to the cue.
Used to enter the Cue menu and activate the Cue list in the DSC. Pressing Loc
will locate to an entered timecode value, allowing the user to move quickly to
any location on the tape.
RollBack allows the user to roll the tape back a determined amount from the
current position. PreRoll is a user-definable amount of time that is added to
any Locate, Cycle, or RollBack.
Auto
The Auto function is currently unsupported.
