Section 9: Dynamics
Accessing Dynamics
Parameters with the
Numeric Keypad
Dynamics Access Menu
Screen Display
Numeric
keypad
key #
Parameter Adjustment Menu
9 - 32
As with adjustment of the EQs, the dynamics can be adjusted by selecting the
parameter from the Numeric keypad and then adjusting the value with the
SpinKnob or the DSC [+]/[–] keys (the Dynamics Access menu must be show-
ing in the SmartDisplay). For some functions the Numeric keypad key will
toggle the value (e.g., you can toggle between Page 1 and Page 2 of the
dynamics screen with the [+]/[–] keys).
If there is a dynamics processor assigned, the graph will appear on the DSC
screen and the last parameter adjusted will come up on the SmartDisplay, in
this case Gate Depth:
Indicates additional menus
Shows which processor
is being adjusted.
(Channel 31 Dynamics 1)
31D1 ->
F1
Dynamics Copy
Accesses
additional menus
By looking at the knobs on the screen you can see which key is used to select
the parameter. For example, on Page 1, the # [7] key selects Compressor
Attack time. This would bring up the SmartDisplay as shown above and allow
the SpinKnob or the DSC [+]/[–] keys to change the value. As the value
changes, the knob on the screen changes and also shows the same parameter
value as in the SmartDisplay.
Select Gate Depth as shown above by pressing the [0] key on the Numeric
keypad. Then press [F3] to enter the Parameter Adjustment menu for Gate
Depth:
(Gate Depth)
Indicates that the
dynamics processor
is switched in.
Parameter being
adjusted (Gate Depth)
Gate Dpth
F2 F3
Goes to the Parameter
Adjustment menu
Bypasses unit
(Dynamics In/Out)
Gate Dpth
F1 F2
Euphonix CS3000/2000 Operation Manual
-> >-
F4
-> >- Dynamics In
– – Dynamics Out
0 dB
F3 F4
