SECTION 1 : AUTOMATED EQ

Overview

EQ object key

Writing EQ Moves

All Parameter Punch

(Iso/Dyn/Trim) LED
i d t
i d t
EQ parameter EQ parameter
punch key control
Individual Parameter
Punch

Playing EQ Moves

Euphonix CS3000/2000 MixView 3.0 Software Supplement
M
ixView v3.0 provides dynamic automation of EQ. All EQ parameters
can be individually punched-in via the DSC rotary controls or simulta-
neously all punched-in via the channel EQ•Dyn attention key.
The EQ is considered an object like the Fader, On and Pan keys, etc. In v3.0
software, the D object key becomes the EQ object key (EQ/D) similar to the
Fader/A, Pan/B and On/C keys. The lone "D" key cap legend will be changed in
future systems to reflect this function.
With a Mix loaded and Mix ON, press
and light the [D] (EQ/D) object key. Give
the system valid forward time code and
observe the Pass Rec light come on.
At this point, if you wish to punch in all parameters of an EQ, press the desired
EQ attention key (EQ1 or EQ2) in the lower fader block.
When all EQ parameters are punched in, you will see all upper idt (Iso/Dyn/
Trim) LEDs next to the EQ rotary controls, the EQ in/out idt LED and the fader
block EQ attention key LED flash, indicating that all EQ parameters are writing.
You can now make changes to any EQ parameter including EQ In/Out and they
will be recorded.
If the EQ is out of circuit during a write, the EQ attention key LED will flash on
momentarily. If the EQ is in circuit during a write, the EQ attention key LED will
flash off momentarily.
To automate individual parameters, punch in by pressing the upper of the two
grey idt keys next to the parameter control you want to automate. The idt LED
for that key and rotary control will flash, indicating that your moves will be
recorded. The EQ in/out parameter is punched in using its idt key on the DSC.
Individual parameter punch does not require the EQ/D object key to be lit to
record. The idt keys are live when ever EQ is displayed on the screen.
Locate your timecode source to the start point and play. Moves written in
automation are seen as the EQ curve changes in real time on the DSC EQ
screen.
Section 1: Automation EQ
Fader Pan On
A B C D
1 - 1
