Section 12: MIDI Remote Control
Remote Control of
Console
SnapShots
Setup
F1
12 - 6
channel and program change), press the [*ST] key to link that preset to the
selected SnapShot. Before establishing the link, a confirmation menu is
displayed:
The double-ended arrow indicates that you can change to another SnapShot at
this time if desired. To complete the link, press the [Enter] key. To confirm the
assignment, press the DSC [SnapShot] key and observe the MIDI preset
number in the SnapShot MIDI column:
The ability to recall a console SnapShot from a second Euphonix console is
very useful in multiple console applications. In two operator systems for
example, you can link Snapshot recall between consoles or recall SnapShots
from any external MIDI controller. Since the intended purpose of this feature is
to facilitate multiple console SnapShot linking, all that is necessary to estab-
lish the link, is to connect MIDI cables between port 4 of both console's MIDI
interface boxes. MIDI channels and console SnapShots will automatically be
connected in numeric order and ready for use.
From the top level MIDI menu, press [F4] (SS->SS) to display the SnapShot
Linking menu:
Snap System Grps
F2 F3 F4
MIDI Menu
In
F1
Both TX (transmit) and RX (receive) parameters default to ON. [F1] and [F3]
toggle TX and RX respectively OFF/ON while [F2] and [F4] direct attention to
MP37 linked
F1 F2
File F-Link
F1
Out Preset SS->SS
F2 F3 F4
TX: ON 1
F1 F2
Euphonix CS3000/2000 Operation Manual
to SS03
F3 F4
GPI MIDI
F2 F3 F4
RX: ON 1
F3 F4
