Cube Aux Masters; Stereo Aux Sends; Naming Aux Sends - Euphonix CS3000 Operation Manual

Section 10: The Audio Cube

Cube Aux Masters

i d t i d t i d t
i d t i d t i d t
i d t i d t i d t
i d t i d t i d t
i d t i d t i d t
i d t i d t i d t
i d t i d t i d t

Stereo Aux Sends

Naming Aux Sends

10 - 14
Press the DSC Aux then Bus Master keys (both are lit). You will see the 6 Aux
Bus Master controls on screen in the lower left.
The Cube aux system works similarly to the console aux system in that there
are fader aux sends to each bus and a aux master bus level.
On screen you see the Aux Master controls, each with a dB readout a meter
and a name block. Screen controls are mapped to the DSC rotary knobs.
i d t
i d t
i d t
i d t
i d t
i d t
Bus Kill switch
i d t
Odd/even buses can be linked as stereo pairs. The lower idt key of the odd
control sets the link. When linked, the odd control is level and even is pan.
The lower idt key of the even control resets the pan to center and the mutes
are linked as well.
While in the top level Aux Bus Master menu, name the aux master, by using
the DSC [+]/[-] keys to select the desired bus then press the keyboard [F1] key.
Type in the name and press [Enter]. You'll see the name appear below the
screen control.
Take this opportunity to enter the names of your effects devices now. They
will appear below the Cube bus master screen controls as well as below the
Cube channel aux send screen controls.
i d t
i d t
Euphonix CS3000/2000 Operation Manual
Adjusts aux send
master level
Aux mute
Stereo link - links
Odd/Even aux masters
as stereo pair.
