Euphonix CS3000/2000 Operation Manual

The ES108A Rear Panel

IN OUT/THRU
MIDI
NOTE: The Output and Ext Key input Elcos have changed locations on the back
panel with the release of the ES108A. Please note this if installing an ES108A
in a rack of ES108s. The Serial Number tag has now been moved to the left
side panel near the power switch (if looking at the unit from the rear) to
accomodate additional enclosure vents.
Ch 1-8 Ch 1-8
OUTPUT INPUT
Section 9: Dynamics
Ch 1-8
EXT KEY
