Auto-Backup

Main Menu
Setup
F1
Setup Menu
Mstr
F1
Backup Interval Menu
Recalling the
Backup SnapShot
Euphonix CS3000/2000 Operation Manual
Normally if the power fails while you are working on a computer-based
console, you might lose changes made since you last saved your settings.
However, the Euphonix has a built-in automatic backup system which stores
the entire console to battery-backed RAM on a regular basis. You can set the
frequency of this auto-backup procedure from the Console Backup menu. If you
ever need to recall the backup SnapShot it is also done via this menu. From
the Main menu, press [F1] (Setup), [F2] (Cnsl), [F4] (Backup) and then [F2] (Int):
Snap System Grps
F2 F3 F4
Cnsl Meter MFdr
F2 F3 F4
backup interval
F1 F2
This is the time between auto-backups. The time interval can be changed by
keying in a new number using the numeric keypad, or by stepping up and down
with the DSC [+]/[–] keys. The range is 1 to 99 minutes.
Press [Esc] once to get to the Backup menu.
Backup:
F1
If your studio experiences a power failure, or if you do something catastrophic,
like recalling a SnapShot when you meant to store it (see page 3-4), you can
recall the last auto-backup.
From the Backup menu, press [F3] (Rcl) to enter the Recall Auto-Backup menu:
RCL
F1
Pressing [F4] will now restore the last backup SnapShot. Press [Esc] once to
get to the Backup menu:
Backup:
F1
[F4] is for future use and is not active in current software revisions.
Section 3: SnapShot Recall
Macs Cnfg
F1 F2
Backup: Int
F1 F2
: 5 min
F3 F4
Int Rcl
F2 F3
backup SnapShot
F2 F3
Int Rcl
F2 F3
Console Menu
Diag Backup
F3 F4
Backup Menu
Rcl
F3 F4
F4
?
F4
F4
3 - 11
