Section 3: SnapShot Recall

Storing (STO) a SnapShot

DSC Assignable
keys
SnapShot Assign-
able key
Store key
SnapShot Mode
key
Page key
Pg 1
Assignable keys
Mon
Select
Mode Select
Using the Master
Control Panel

IMPORTANT!

Momentary display:
3 - 6
1 9
2 10
3 11
4 12
13
5
6 14
7 15
8 16
Faders Store
Pg 2 Pg 3 Pg 4
Mon Snap
Preset Studio Macro
Cnfg
Shot
Another way to store a SnapShot is to use the Master Control Panel. Use the
SpinKnob or the numeric keypad to select 16 in the display above F4.
**SS=11
Next press [F3]. This toggles between Store (STO) and Recall (RCL) as indi-
cated above [F3]. It also brings up a prompt on the screen display so you can
enter the name of the SnapShot from the keyboard. It is possible to save the
SnapShot without naming it. Press [F4] to store.
Make sure STO not RCL shows in the display above F3 before you press F4 or
you will lose your SnapShot! You can also press the [Enter] key instead of F4
to store the current console into the SnapShot indicated above F4.
**SS=11
Press [F4]:
Then:
**SS=16
The current desk has now been stored to 16. Note that the left number now
indicates that 16 is the active SnapShot and [F3] has returned to RCL.
SnapShots can be stored using the DSC Assignable
Keys or the Master Control Panel. From the DSC Assign-
able Keys section, press the SnapShot mode key. This
puts the Assignable Keys in SnapShot mode. Next press
the Store key and name your SnapShot from the key-
board, then select the SnapShot page (Pg 1-4). Each
page displays 16 SnapShots except Page 4 which
displays 49 & 50 and the Default, Auto Null On/Off, and
Physical keys. Store the SnapShot to a specific
SnapShot number by pressing the corresponding
Assignable Key. For example, to store console settings
into SnapShot memory 16, press the [Snap]shot Mode
key, the [Store] key, name the SnapShot, press the [Pg
1] key and then press the #16 SnapShot Assignable Key.
This procedure saves the current state of the console to
SnapShot memory #16.
a
F1 F2
a
F1 F2
...SnapShot STORED
F1 F2
a
F1 F2
Euphonix CS3000/2000 Operation Manual
RCL 16
F3 F4
STO 16
F3 F4
16
F3 F4
RCL 16
F3 F4
