Dynamics User Presets - Euphonix CS3000 Operation Manual

Dynamics User
Presets
Dynamics
31D1->
Access Menu
F1
Preset Menu
Shows to which channel
the dynamics preset will be
recalled, and also to which
dynamics processor in that
channel (Dyn1 or Dyn2)
Shows last recalled
or stored user preset
Euphonix CS3000/2000 Operation Manual
The Dynamics User Preset Library is saved with system information. This is a
store of 100 user-programmable dynamics settings and are available from
every project and title. Note that dynamics settings are stored in SnapShots
just as other console settings like EQs, routing, etc. The Preset Library is useful
for storing settings that you frequently use. For example, you could save a
preset with only high pass and low pass filters in the signal path, another for a
compressor set specifically for vocals, and so on.
Customized User
Preset Library
From the Dynamics Access menu, press [F2] (down arrows) and then [F1]
(Preset):
Gate Dpth -> >-
F2 F3 F4
31D1 1u
F1 F2
Toggles between
RCL and STO
modes
Toggles between
user presets and
factory presets
To store a user preset, configure the dynamics processor the way you want it
set, and enter the preset menu. Select the preset number using the SpinKnob,
then toggle RCL to STO by pressing [F3]. Name the preset using the QWERTY
keyboard, and store by pressing [F4] or [Enter].
Preset Assign
F1 F2
RCL 2u
F3 F4
Recall/store
the selected
user preset
Shows that preset
recall (RCL) is enabled
Section 9: Dynamics
Calib
F3 F4
SpinKnob scrolls
through presets
on the screen.
+
Bus
-
DIR
*
ST
DSC [+]/[–] keys
recall presets as
they are scrolled
9 - 47
