Section 5: The Patchbay
Normalling the
Audio CUBE
5 - 10
• "1-per-channel" Audio CUBE System:
The inputs to the Audio CUBE (up to 48) are normalled from the Dir1/Dir2
connector. Only the Dir1 pins are populated.
• "2-per-channel" Audio CUBE System:
The inputs to the Audio CUBE (up to 48) are normalled from the Dir1/Dir2
connector. Both the Dir1 and Dir2 pins are populated.
Some systems (depending on the number of channels) are a combination of 1-
per-channel and 2-per-channel cabling. See the Audio CUBE Installation and
Service Manual for wiring configuration diagrams for various Euphonix mixing
systems.
