Chapter 62 Configuring Call Home
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
Table 62-7 Inventory Event Message Format (continued)
Data Item Description
(Plain text and XML) (Plain text and XML)
Device ID Unique Device Identifier (UDI) for end device generating message.
This field should empty if the message is non-specific to a fabric switch.
Format: type@Sid@serial, where
•
•
•
•
Example: DS-C9509@C@12345678
Customer ID Optional user-configurable field used for contact info or other ID by any
support service.
Contract ID Optional user-configurable field used for contact info or other ID by any
support service.
Site ID Optional user-configurable field, can be used for Cisco-supplied site ID
or other data meaningful to alternate support service.
Server ID If the message is generated from the fabric switch, it is the Unique
device identifier (UDI) of the switch.
Format: type@Sid@serial, where
•
•
•
•
Example: "DS-C9509@C@12345678
Message description Short text describing the error.
Device name Node that experienced the event.
Contact name Name of person to contact for issues associated with the node
experiencing the event.
Contact e-mail E-mail address of person identified as contact for this unit.
Contact phone Phone number of the person identified as the contact for this unit.
number
Street address Optional field containing street address for RMA part shipments
associated with this unit.
OL-17256-03, Cisco MDS NX-OS Release 4.x
type is the product model number from backplane SEEPROM.
@ is a separator character.
Sid is "C" identifying the serial ID as a chassis serial number·
serial is the number identified by the Sid field.
type is the product model number from backplane SEEPROM.
@ is a separator character.
Sid is "C" identifying the serial ID as a chassis serial number·
serial is the number identified by the Sid field.
Cisco MDS 9000 Family Fabric Manager Configuration Guide
Message Contents
XML Tag
(XML only)
/mml/ header /deviceId
/mml/header/customerID -
ch-inv:CustomerId
/mml/header/contractId -
ch-inv:ContractId>
/mml/header/siterId -
ch-inv:SiteId
/mml/header/serverId -
-blank-
/mml/body/msgDesc -
ch-inv:MessageDescription
/mml/body/sysName -
ch-inv:SystemInfo/Name
/mml/body/sysContact -
ch-inv:SystemInfo/Contact
/mml/body/sysContacte-mail
-
ch-inv:SystemInfo/Contacte-
mail
/mml/body/sysContactPhone
Number -
ch-inv:SystemInfo/ContactPh
oneNumber
/mml/body/sysStreetAddress -
ch-inv:SystemInfo/StreetAddr
ess
