Chapter 64 Configuring Fabric Congestion Control and QoS
S e n d d o c u m e n t a t i o n c o m m e n t s t o m d s f e e d b a c k - d o c @ c i s c o . c o m
•
Tip The order of entries to be matched within a class map is not significant.

Creating a Class Map

To create a class map using Fabric Manager, follow these steps:
Expand Switches, expand FC Services and then select QoS in the Physical Attributes pane.
Step 1
The QoS information is displayed in the Information pane shown in
default.
Figure 64-3
In the Class Maps tab, click Create Row to create a new class map.
Step 2
You see the Create Class Maps dialog box shown in
Figure 64-4
Select the switches for the class map.
Step 3
Enter the source ID or the destination ID in the field.
Step 4
Enter a name for the class map.
Step 5
Select a Match mode.You can either match any or all criterion with one match statement from the class
Step 6
map configuration mode.
Click Create to proceed with creating the class map.
Step 7
OL-17256-03, Cisco MDS NX-OS Release 4.x
Source interface—The ingress interface.
Quality of Service Control Tab
Create Class Maps Dialog Box
Figure
Figure 64-4.
Cisco MDS 9000 Family Fabric Manager Configuration Guide
QoS
64-3. The Control tab is the
64-7
