LDO CONFIGURATIONS
Table 125. Example LDO Modes and Pin Mapping (Continued)
Index LDO
5 GP_LDO_2
6 RX_2_LO_LDO
7 TX_2_LO_LDO
8 CLK_PLL_SYNTH_LDO
9 CLK_PLL_VCO_LDO
10 CLK_PLL_LP_SYNTH_LD
O
11 CLK_PLL_LP_VCO_LDO
12 LO1_PLL_SYNTH_LDO
13 LO1_PLL_VCO_LDO
14 LO2_PLL_SYNTH_LDO
15 LO2_PLL_VCO_LDO
16 AUX_PLL_SYNTH_LDO
17 AUX_PLL_VCO_LDO
18 SRAM_LDO
The following is the C# implementation of this configuration.
adi_adrv9001_PowerManagementSettings_t initialize_powerManagementSettings_35 = {
.ldoPowerSavingModes = { ADI_ADRV9001_LDO_POWER_SAVING_MODE_1,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_1, ADI_ADRV9001_LDO_POWER_SAVING_MODE_5,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_5, ADI_ADRV9001_LDO_POWER_SAVING_MODE_5,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_2, ADI_ADRV9001_LDO_POWER_SAVING_MODE_2,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_2, ADI_ADRV9001_LDO_POWER_SAVING_MODE_1,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_1, ADI_ADRV9001_LDO_POWER_SAVING_MODE_1,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_1, ADI_ADRV9001_LDO_POWER_SAVING_MODE_3,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_2, ADI_ADRV9001_LDO_POWER_SAVING_MODE_3,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_2, ADI_ADRV9001_LDO_POWER_SAVING_MODE_1,
ADI_ADRV9001_LDO_POWER_SAVING_MODE_1, ADI_ADRV9001_LDO_POWER_SAVING_MODE_1 }
analog.com
LDO Mode Output Pin
2 VANA2_1P0
2 VRX2LO_1P0
2 VTX2LO_1P0
1 N/A
1 VCLKVCO_1P0
1 N/A
1 VCLKVCO_1P0
3 N/A
2 VRFVCO1_1P0
3 N/A
2 VRFVCO2_1P0
1 N/A
1 VAUXVCO_1P0
1 VDIG_0P9
ADRV9001
Output Pin Number Comments
C6 Powered off, ch2 not
required.
E1 Powered off, ch2 not
required.
H3 Powered off, ch2 not
required.
N/A Left on.
H5 Left on.
N/A Left on.
H5 Left on.
N/A Powered off, using external
LO.
B9 Powered off, using external
LO.
N/A Powered off, LO2 not
required.
B6 Powered off, LO2 not
required.
N/A Left on.
H10 Left on.
M8 Left on.
Rev. 0 | 304 of 351
