RECEIVER/OBSERVATION RECEIVER SIGNAL CHAIN
Table 60. A List of Interface Gain APIs (Continued)
Receiver Interface Gain API Function Name
adi_adrv9001_Rx_InterfaceGain_Get
adi_adrv9001_Rx_DecimatedPower_Get
Table 61. A List of Rx Miscellaneous APIs
Receiver Miscellaneous API Function Name
adi_adrv9001_Rx_Rssi_Read
adi_adrv9001_Rx_FrequencyCorrection_Set
adi_adrv9001_Rx_AdcSwitchEnable_Set
adi_adrv9001_Rx_AdcSwitchEnable_Get
adi_adrv9001_Rx_AdcSwitch_Configure
adi_adrv9001_Rx_AdcSwitch_Inspect
adi_adrv9001_Rx_AdcType_Get
adi_adrv9001_Rx_PortSwitch_Configure
adi_adrv9001_Rx_PortSwitch_Inspect
adi_adrv9001_Rx_ExternalLna_Configure
adi_adrv9001_Rx_ExternalLna_DigitalGainDelay_Set
adi_adrv9001_Rx_ExternalLna_DigitalGainDelay_Get
adi_adrv9001_Rx_Loid_Configure
adi_adrv9001_Rx_Loid_Inspect
analog.com
Description
Gets the receiver interface gain for the given receiver channel.
Gets the decimated power at configurable locations for the specified channel.
Description
Reads the received signal power measurement in both the linear and dB format.
Corrects small deviations in the receiver LO frequency offset.
Sets the readiness of the dynamic switch between Low Power and High Performance ADCs.
Gets the readiness of the dynamic switch between Low Power and High Performance ADCs.
Configures ADC dynamic switch settings for the specified channel.
Inspects the current ADC dynamic switch settings for the specified channel.
Gets the current ADC type for the specified channel.
Configures receiver port switching.
Inspects the current receiver port switching settings.
Configures the external LNA for the desired receiver channel.
Sets LNA digital gain delay for the desired receiver channel.
Gets LNA digital gain delay for the desired receiver channel.
Configures LOID settings.
Inspects LOID settings.
