TRANSMITTER/RECEIVER/OBSERVATION RECEIVER SIGNAL CHAIN CALIBRATIONS
Table 62. Initial Calibration Mask Bit Assignments (Continued)
Bits Corresponding Enum
D22 ADI_ADRV9001_INIT_CAL_PLL
D23 ADI_ADRV9001_INIT_CAL_AUX_PLL
The ADRV9001 ARM proceeds through the calibrations in the required sequential order. The system's initial calibrations are performed first,
followed by receiver initial calibrations, and then transmitter initial calibrations.
and the transmitter initial calibration order, respectively.
Table 63. Rx Initial Calibration Order
Order
1
2
3
4
5
6
7
8
9
10
11
12
13
Table 64. Tx Initial Calibration Order
Order
1
2
3
4
5
6
7
8
9
The calibration order is mostly determined by the algorithm dependency. It is important to wait for these calibrations to complete successfully
before continuing with the other steps of initialization for the device.
Note: Table 62 provides a full list of initialization calibrations for the device.
System Considerations for Transmitter Initial Calibrations
In this section, high level block diagrams show the device configurations and external system requirements for some transmitter initial
calibrations. In all the diagrams, grayed-out lines and blocks are not active in the calibration. Note that as the ADRV9001 ARM performs each
of the calibrations, it configures the ADRV9001 device per the following diagrams, with respect to enabling/disabling paths, and so on. No user
input is required in this regard. However, it is important that external system conditions are met, such as having the power amplifier off for all
calibrations except for some initialization calibrations utilizing ELB2.
analog.com
Calibration
PLL Initial
Calibration
AUX PLL Initial
Calibration
Table 63
Receiver Initial Calibrations
RX_HPADC_RC
RX_HPADC_FLASH
RX_HPADC_DAC
RX_LPADC
RX_TIA_CUTOFF
RX_DCC
RX_GROUP_DELAY
RX_RF_DC_OFFSET
RX_GAIN_PATH_DELAY
RX_QEC_ILB_LO_DELAY
RX_QEC_TCAL
RX_QEC_FIC
RX_DMR_PATH_DELAY
Transmitter Initial Calibrations
TX_DCC
TX_BBAF
TX_DAC
TX_LB_PD
TX_LO_LEAKAGE
TX_QEC
TX_BBAF_GD
TX_ATTEN_DELAY
TX_PATH_DELAY
Description
Performs VCO frequency calibration, VCO real-time temperature/aging
calibration, and charge pump calibration to make RF PLL ready for
operation. It is only used for very fast frequency hopping mode. This is
not enabled currently.
Performs VCO frequency calibration, VCO real-time temperature/aging
calibration, and charge pump calibration to make aux PLL ready for
operation. This is not enabled currently.
and Table 64 show the receiver initial calibration order,
