Reference Manual
TRANSMITTER/RECEIVER/OBSERVATION RECEIVER SIGNAL CHAIN CALIBRATIONS
Figure 146. Tx LO Leakage Performance When LO Change = 100MHz with Full Init Cals, Min Init Cals and No Init Cals
Figure 147. Tx Image Rejection Performance When LO Change = 100MHz with Full Init Cals, Min Init Cals and No Init Cals
Table 65. Initial Calibration Comparison Summary
Bits Enum
D0 TX_QEC
D1 TX_LO_ LEAKAGE
D2 TX_LB_PD
D3 TX_DDC
D4 TX_BBAF
D5 TX_BBAF_GD
D6 TX_ATTEN_ DELAY
D7 TX_DAC
analog.com
User Override Run at
Rerun after LO
Capability Boot
Change
>100 MHz
Yes Yes Yes
Yes Yes Yes
Yes Yes No
No Yes Yes
No Yes No
No Yes Yes
No Yes No
No Yes No
Signal Used by External
Calibration Termination
(Tones, Wide- Needed
band, None)
Tone Yes
Wideband Yes
Wideband Yes
Tone Yes
Tone Yes
Tone Yes
Tone Yes
None No
ADRV9001
Dependent on Which Init Cals
is Run First
TX_DAC, TX_BBAF, all
Receiver Init Cals on ILB,
TX_LB_PD
TX_DAC, TX_BBAF, all
Receiver Init Cals on ILB and
ELB, TX_LB_PD
TX_DAC, TX_BBAF,
RX_HPADC_RC,
RX_HPADC_FLASH,
RX_LPADC, RX_TIA_CUTOFF,
RX_RF_DC_OFFSET
None
None
TX_BBAF, TX_QEC
TX_DAC, RX_HPADC_RC,
RX_HPADC_FLASH,
RX_LPADC
None
Rev. 0 | 157 of 351
