Installation Planning Guide
6.
Printer specifications and
requirements
This chapter provides power and space requirements for your
96/4635/180 printer. It also provides printer environmental
specifications.
For facts about controller power and space requirements, refer to
the "Controller specifications and requirements" chapter of this
guide.
Your 96/4635/180 printer has important power requirements that
must be accommodated. These requirements are summarized in
the table below. For further details on power requirements, refer
to the voltage charts and wiring diagrams that follow.
For details on controller power requirements, refer to the
"Controller specifications and requirements" chapter of this
guide.
Table 6-1. Printer electrical requirements
Voltage
120/240 VAC or 120/208 VAC
(Cord 1)
120/240 VAC or 120/208 VAC
(Cord 2)
120/240 VAC or 120/208 VAC 50 amp
220, 230, 240 VAC
(3 phase, 4 wire)
380, 400, 415 VAC
(3 phase, 5 wire)
Amp.
service
KVA rating
50 amp
Operating: 7.3
(Cord 1)
+ .75 per middle
module stacker
30 amp
(Cord 2)
Operating: 7.3
+ .75 per middle
module stacker
30 amp
Consult local
service rep.
20 amp
Consult local
service rep.
NEMA
14-50R
(Cord 1)
14-30R
(Cord 2)
14-50R
6-1
