Xerox DocuPrint
96/4635/180/2000
Series NPS/IPS
Installation Planning Guide
721P90100
Version 8.0
October 2002

Advertisement

Table of Contents
loading

  Related Manuals for Xerox DocuPrint 100

  Summary of Contents for Xerox DocuPrint 100

  • Page 1 Xerox DocuPrint 96/4635/180/2000 Series NPS/IPS Installation Planning Guide 721P90100 Version 8.0 October 2002...
  • Page 2 Printed in the United States of America. Publication number: 721P90100 Xerox® and all Xerox products mentioned in this publication are trademarks of Xerox Corporation. Products and trademarks of other companies are also acknowledged. Changes are periodically made to this document. Changes, technical...
  • Page 3: Table Of Contents

    Table of contents Safety ..........ix Laser safety .
  • Page 4 Responsibilities ......... . . 4-1 Xerox responsibilities ....... . . 4-1 Customer responsibilities .
  • Page 5 Space requirements ........6-6 Printer placement ........6-7 Bypass transport specifications .
  • Page 6 Ordering supplies ........A-23 B. Xerox support services ........B-1 Xerox Customer Service Support Center .
  • Page 7 Configuration steps – MVS ......F-2 Correcting for printer performance issues – MVS ..F-19 References –...
  • Page 8 Table of contents viii Installation Planning Guide...
  • Page 9: Safety

    The laser danger labels on the system are for Xerox service representatives and are on or near panels or shields that must be removed with a tool.
  • Page 10: Ozone Information: U. S. Only

    1-800-828-6571 to request the Xerox publication 600P83222, OZONE. Operation safety: U. S. Your Xerox equipment and supplies have been designed and tested to meet strict safety requirements. They have been approved by safety agencies, and they comply with environmental standards.
  • Page 11: Operation Safety: Europe

    Disconnect the power cord from the electrical outlet and call service to correct the problem. If you need any additional safety information concerning the equipment or materials Xerox supplies, call Xerox Product Safety at the following toll-free number in the United States: 1-800-828-6571 For customers outside the United States, contact your local Xerox representative or operating company.
  • Page 12: Electrical Supply

    This product should not be placed in a built-in installation unless proper ventilation is provided, please contact your Xerox representative for advice. Never push objects of any kind into the ventilation vents of the product.
  • Page 13: Maintenance

    A full declaration of conformity, defining the relevant directives and referenced standards, can be obtained from your Xerox representative. In order to allow this equipment to operate in proximity to...
  • Page 14: Radio And Telecommunications Equipment Directive (Europe Only)

    Radio and telecommunications equipment directive (Europe only) Certification to 1999/5/EC Radio Equipment and Telecommunications Terminal Equipment Directive: This Xerox product has been self-certified by Xerox for pan- European single terminal connection to the analog public switched telephone network (PSTN) in accordance with Directive 1999/5/EC.
  • Page 15: For Further Information

    For further information For more information on Environment, Health and Safety in relation to this Xerox product and supplies, please contact the following customer help lines: Europe:+44 1707 353434 USA:1 800 8286571 Canada:1 800 8286571 Installation Planning Guide...
  • Page 16 Safety Installation Planning Guide...
  • Page 17: Introduction

    About this guide This guide is intended for the person responsible for coordinating the installation of the DocuPrint printer at your site. It lists the tasks you must complete before installation can begin, as well as your responsibilities during the installation.
  • Page 18 DocuPrint printing system. It also provides a list of consumable supplies you can order. • Appendix B, "Xerox support services," explains how to utilize available Xerox support services. • Appendix C, "Related publications," lists other Xerox documents that are part of this publication set.
  • Page 19: Notice

    Warnings alert you to conditions that may affect the safety of people. Notice This publication may contain descriptions of concepts and features not currently available for your Xerox printing system. Consult your Xerox sales representative or your operating system software program description for additional information. Installation Planning Guide...
  • Page 20 Introduction Installation Planning Guide...
  • Page 21: System Overview

    This chapter provides an overview of the features and functions of the Xerox DocuPrint NPS/IPS. Functional overview of the NPS/IPS The NPS/IPS printers support the processing and printing of PDL and ASCII jobs from network workstations, as well as IPDS jobs from an IBM host.
  • Page 22: Throughput Speed

    The following table shows how data streams of different resolutions are interpolated. Incoming input resolution of document Printer 240 dpi data 180 NPS/IPS Interpolated by printer to 600 x 1920 dpi 96/4635 NPS/IPS Converted by controller to 300 or 600 dpi, then interpolated by printer to 600 dpi Table 1-1.
  • Page 23: System Components Overview

    The entire DocuPrint NPS/IPS system includes the printer (also known as an IOT or print engine), printer controller, printer interface, and all appropriate software. “DocuPrint printer” or “printer” refers to the base printer engine (IOT) only, without the printer controller and interface. Xerox-supplied...
  • Page 24: Nps/Ips Concurrent Printing

    Ethernet connection can be used for jobs submitted over the network. NPS/IPS concurrent printing The Xerox NPS/IPS can receive a variety of data streams including IPDS, PostScript Levels 1 and 2, PCL 5e, TIFF, and ASCII. The system automatically senses the type of job and processes it appropriately.
  • Page 25: Connectivity Configurations

    Ethernet connection can be used for jobs submitted over the network. NPS/IPS concurrent printing The Xerox NPS/IPS can receive a variety of data streams including IPDS, PostScript Levels 1 and 2, PCL 5c, PCL 5e, TIFF, and ASCII. The system automatically senses the type of job and processes it appropriately.
  • Page 26 PSF/2, PSF/6000, or InfoPrint Manager can attach to a PSF/VSE system and the PSF/2, PSF/6000, or InfoPrint Manager can furnish the TCP/IP support for the printer. NOTE: There is no minimum host operating system software level required. The minimum PSF level needed to support full color is v.3.2.
  • Page 27 2. Interface network (Ethernet or Token Ring) 3. Printer controller 4. Printer interface cables 5. Printer For information on the various printer configuration options, refer to the “Printer components and options” chapter of this guide. Installation Planning Guide System overview...
  • Page 28: Channel Interface Board And Channel Cable Connector Box- Channel-Attached Systems Only

    NPS/IPS is printing data using TCP/IP.) Figure 1-3. Channel interface board and connector box 1. Printer 2. Printer control and video cable 3. Printer controller with channel interface board 4. Channel cable connector box 5. Channel cables 6. Host system NOTE: The customer is responsible for obtaining, stringing, and maintenance of the bus and tag cables.
  • Page 29: Host Channel Unit (Hcu)-Channel-Attached Systems Only

    IBM 3825 and 3827 printers are supported by the Xerox software. Additionally, the data towers that are supported within the AFP environment by the IBM 3825 and IBM 3827 printers are fully supported by the software. Data towers supported are: •...
  • Page 30: Network Pdl Printing Environment

    Network PDL printing environment Figure 1-5. DocuPrint printer system components 1. Customer-supplied client PC or workstation 2. Customer-supplied network 3. Xerox-supplied printer controller 4. Xerox-supplied printer interface 5. DocuPrint printer Customer- Users create their documents at the networked client PCs or...
  • Page 31: Networks

    Engineers (IEEE) 802.3 standard. Token Ring Users of network client workstations may send print jobs to the printer over Token Ring network using TCP/IP, Novell 3.x, or AppleTalk network protocol. Regardless of printing transmission protocol, the Token Ring connection to the printer controller must be compatible with the Institute of Electrical and Electronics Engineers (IEEE) 802.5...
  • Page 32: Network Client Components

    Supported client hardware and operating systems Xerox NPS/IPS supports the following types of networked client workstations and operating systems: – Sun workstation running a Sun or Linux operating system –...
  • Page 33: Client Networking Software

    Ethernet LAN or Token Ring network, transceivers, cables, and connectors. Xerox is responsible for the physical installation and service of the printer and printer controller hardware and software components. You have the general responsibility for the site of ensuring that the right personnel, supplies, and that network hardware and software is available.
  • Page 34: Sixth Sense

    Sixth Sense is a no charge feature available to customers through Xerox Service. The customer need only provide an analog phone line for use by the Sixth Sense modem connection. For those customers unable to dedicate a phone line to the Sixth Sense connection, three and five port phone share devices are available for purchase.
  • Page 35: Controller Components And Options

    Printer controller components The printer controller consists of a specially-configured Sun workstation and uses proprietary Xerox hardware, firmware, and software. Your system may use one of two platforms for the printer controller: •...
  • Page 36 Controller components and options • Optional Token Ring board • Two printer controller Interface (PCI) boards installed in the processor to interface with the print engine. Optional For channel connection to a host for IPDS printing, the system components may use a channel interface board that is connected to a channel cable connector box.
  • Page 37 • Memory: Four 1 GB Dual In-line Memory Modules, or DIMMs are provided as a standard feature of the processor. • Hard disk drive: A 36 GB primary disk drive is provided as a standard feature of the processor. The operating system, the NPS/IPS application, and any queued print jobs are stored on the internal disk.
  • Page 38 Controller components and options Figure 2-2. Back panel of the printer controller 1. Access panel lock block 2. Serial connectors A and B, DB-25 3. Parallel connector 4. SCSI connector 5. Universal serial bus (USB) connectors 6. Twisted-pair Ethernet (TPE) connector 7.
  • Page 39: Sun Ultra 60 Workstation

    Use the mouse to select, move, or resize windows. Display monitor The 18.1-inch LCD monitor allows you to interact with the printer and to monitor its interaction with the various components. During a print job, printer error messages may display to notify you of any unexpected conditions.
  • Page 40 Controller components and options Figure 2-3. Printer controller components (Sun Ultra 60) 1. Monitor 2. Keyboard 3. Mouse 4. Processor 5. Diskette drive 6. CD-ROM 7. Optional cartridge tape drive 8. Optional HCU Processor The central processing unit contains the memory, internal disk drive, a CD-ROM drive, a diskette drive, power receptacle and outlet, connectors and ports.
  • Page 41: Printer Controller Software And Fonts

    Installation Planning Guide NOTE: The Sun operating system used on the controller is based on the standard Sun operating system; however, it has been customized for use with the Xerox printer controller. Therefore, not all standard Sun operating system features are available.
  • Page 42 Controller components and options – DocuPrint Print Service Software including software • Xerox Client Software – Xerox client protocol software (print command); can be • Adobe Type 1 PostScript fonts – Courier (Courier, Bold, Oblique, Bold Oblique) – Helvetica (Helvetica, Bold, Oblique, Bold Oblique, Light, –...
  • Page 43 – Times new Roman (Medium, Italic, Bold, Bold Italic) – Symbol (Medium) – Wingdings (Medium) • PCL fonts: Bitmap – Line Printer (16.67 pitch / 8.5 point medium) NOTE: The resident fonts are used for PostScript and PCL printing. Installation Planning Guide (Bold), Kursiv Halbfett (Bold Italic)]...
  • Page 44 Controller components and options 2-10 Installation Planning Guide...
  • Page 45: Printer Components And Options

    Printer components The components of the 4635 and 180 NPS/IPS base printer are shown in the following figure. The 96 NPS/IPS standard printer configuration has one inverter feeder/stacker module, with the option of adding a second feeder/stacker module as shown.
  • Page 46 Printer components and options NOTE: The DocuPrint MICR NPS/IPS models utilize the same hardware and operating system as the non-MICR NPS/IPS models. However, the Image Development systems have been modified to enable MICR font reproduction. Processor feeder Two processor feeder trays are located in the main part of the...
  • Page 47 3. Tray Unlock button You can use this button any time the Please Wait indicator is off. • • • 4. Paper Level indicators These indicators display the approximate quantity of paper within the tray. The display shows paper by quarter reams up to one ream, and then by full reams.
  • Page 48 (HCS) bins as part of the feeder/stacker modules (stacker bins A, B, C and D). The 96 NPS/IPS printer can contain up to two high-capacity stacker (HCS) bins as part of the feeder/stacker modules (stacker bins A and B).
  • Page 49 An attention light is mounted on top of the inverter module. The attention light signals when the printer requires operator attention: • Off: No printer problems exist that require your attention. • Steady light: A situation exists that needs your attention (such as low dry ink condition).
  • Page 50 The button is disabled for MICR printers. Sample tray The sample tray located on top of the printer holds up to 100 sheets of paper. It receives output such as transparencies, sample prints or system files, and waste sheets that cannot be sent to the purge tray.
  • Page 51 Figure 3-5. Printer console 1. Language icon 2. Printer icon 3. Fault List icon 4. Tools icon 5. Guarded Tools icon (not available on the 96 NPS) 6. Clear button 7. Continue button 8. Stop button 9. Sample button 10. Brightness control thumbwheel 11.
  • Page 52: Printer Configurations

    The DocuPrint 96, 4635, and 180 NPS/IPS are available in the following configurations, some of which may include the bypass transport and/or Input Enablement kit. Figure 3-6. DP 96 NPS/IPS: Printer + inverter feeder/stacker The DocuPrint 4635 and 180 are available in the configurations shown in the following figures.
  • Page 53 Figure 3-8. Printer + inverter feeder/stacker + feeder/stacker + feeder/stacker + bypass transport Figure 3-9. Printer + inverter feeder/stacker + feeder/stacker + feeder/stacker Figure 3-10. Printer + inverter feeder/stacker + feeder/ stacker + feeder/stacker + bypass transport Figure 3-11. Printer + inverted feeder/stacker + feeder/...
  • Page 54: Paper Paths

    IPS only. Paper paths The paper path is the route that materials (paper, transparencies, labels, and so on) follow through the printer from the feeder trays to the output trays. Paper path The following figure illustrates the entire printer paper path.
  • Page 55 1. Processor feeder tray 1 2. Processor feeder tray 2 3. High-capacity feeder tray 3 4. Side 1 of sheet leaving feeder tray 5. Drilled holes (on right edge) 6. Origin 0,0: portrait feeder tray 4 7. High-capacity feeder tray 4 8.
  • Page 56 Input enablement The following figure shows the paper path and the dimensions of paper path the input enablement area from a printer front view. The input enablement kit option supports third-party feeding devices. Figure 3-13. Input enablement paper path and dimensions...
  • Page 57: Installation

    The following figure shows the dimensions of the bypass transport portion of the paper path. Figure 3-14. Bypass transport dimensions Installation Planning Guide 3-13...
  • Page 58 Printer components and options 3-14 Installation Planning Guide...
  • Page 59: Preparing For Installation

    Xerox DocuPrint 96/4635/180 NPS/IPS and 96/4635/180 MICR NPS/IPS. Preparing for installation is a responsibility shared by personnel at your site and Xerox. Your service representatives are available to discuss installation issues and to assist you in completing the site installation tasks.
  • Page 60: Customer Responsibilities

    Refer to the “DocuPrint NPS/IPS installation planning checklist” and the “Network preinstallation checklist” in this chapter for a complete list of responsibilities. Refer to the “Xerox support services” appendix for information on services designed to support you prior to, during, and after your installation.
  • Page 61 This conversion is required for DocuPrint 96/4635 MICR NPS/IPS. address to your Xerox representative. connect client workstations to the printer controller. Refer to the “Network preinstallation checklist” in this chapter. NOTE: You are responsible for obtaining, stringing, and maintaining fully-populated bus and tag cables for channel-attached systems.
  • Page 62: Installation Planning Checklist

    – Set up the operator training schedules. • Applications – Work with your Xerox system analyst to determine – In a mixed environment, where there is a variety of Make sure that your system specialists are familiar with the operating system software specific to your IPS; operating system software is not the same for all laser printing systems.
  • Page 63 DocuPrint NPS/IPS. • In the United States, sign up with Xerox Documentation and Software Services. Order additional documentation, if needed. • In the United States, register for Xerox Customer Education classes, if needed.
  • Page 64 Generate the host for an AFP1 device and IPL, as required. – Provide analog phone line access for optional Sixth Sense installation. Reference Responsibility Sales rep Customer and Chapters 4 to 6 Xerox Customer Installation Planning Guide Date completed _________ _________ _________ _________ _________ _________...
  • Page 65 • Schedule operator training. • Define parameters needed to configure PSF for connectivity to the NPS/IPS printer. Installation Planning Guide Reference Responsibility Xerox Chapter 4, Customer and Appendix A and Xerox sales rep Systems analyst Customer and Xerox Date...
  • Page 66 AFP Type 1, Group 3 printer. • Set up Data Transfer Mode. • Install DocuPrint system hardware and software. • Load Xerox client software on client workstations. • Have operators available for training. • Check documentation and software kits for completeness.
  • Page 67: Nps/Ips Network Installation Checklist

    IP addresses you assign must belong on different TCP/IP subnets, as determined by the IP subnet netmask. • If you are not on a TCP/IP network, use the Xerox-supplied IP address value (192.9.200.1), or the IP address value assigned by your network administrator. IP netmask Series of four integers between 0 and 255 separated by a period, such as 255.255.255.0 to create an IP netmask.
  • Page 68 • If you are on a TCP/IP network, assign a valid IP netmask. • If you are not on a TCP/IP network and you used the Xerox- supplied IP address value (192.9.200.1), use 255.255.255.0 for the IP netmask. IP broadcast...
  • Page 69 To keep your system running at optimum speed, you need to periodically purge accounting data. Xerox client Indicate whether you have Xerox client software installed, and software are supporting Xerox clients on the network. lpr and lpd Indicate whether to enable client use of lpr and lpd job submission and status commands.
  • Page 70: Novell Network Information

    The Novell network information you provide to your service representative is based on whether you configure the DocuPrint as a print server or a remote printer. Refer to this chapter and your Novell network administrator for assistance, if necessary. DocuPrint as a print server (PSERVER)
  • Page 71: Docuprint Nps/Ips As A Remote Printer (Rprinter)

    Novell internet. • Printer names to service: Refers to the name or names of the printers defined for the Novell print server. Virtual printers should be defined with these names after DocuPrint NPS/IPS installation is complete.
  • Page 72 Choose a framing type used by the file server that communicates with DocuPrint NPS/IPS. If you are using print server or remote printer, and have the DocuPrint NPS/IPS communicate with a different machine for each, then choose a framing type that is used by both of the machines.
  • Page 73: Connectivity Requirements

    HCU. This network communication system is used to transport documents from the client workstation to the printer. Ethernet specifications Reviewers: Should we keep the second or the third...
  • Page 74: Token Ring Specifications

    Terminators (if necessary, due to location on channel). For your convenience, it is possible to order the bus and tag cables for the printer through Xerox on a purchase-only basis. Contact your Xerox sales representative for current pricing and order information.
  • Page 75: Controller Specifications And Requirements

    This chapter provides power and space requirements for your DocuPrint NPS/IPS printer controller. It also provides controller environmental specifications. For facts about printer power and space requirements, refer to the “Printer specifications and requirements” chapter of this guide. Power requirements Your DocuPrint NPS/IPS controller has important power requirements that must be accommodated.
  • Page 76: Outlet Configurations

    • Each power cord has a separate circuit • The printer power cord configurations match your receptacle • Your electrical outlets are within the required specifications. 50 Hz systems: Ensure that power connections are per local codes/regulations.
  • Page 77: Environmental Specifications

    Environmental specifications The environmental requirements for the DocuPrint NPS/IPS controller are all satisfied by the printer module. Refer to the “Printer specifications and requirements” chapter of this guide. Table 5-2. Heat dissipation specifications for the DocuPrint...
  • Page 78 Controller specifications and requirements You must supply a table or desk as a work surface for the printer controller, and the HCU if this is part of the system configuration. The top of the table must provide at least 36 by 36 inches / 91 by 91 cm of space for each component, to allow enough space for the components and cables, as well as for service access.
  • Page 79 • Do not place the processor on its side, or in any other position but the upright, vertical position. • Do not place the processor or monitor on top of the printer. Installation Planning Guide...
  • Page 80 • Place the monitor and processor on a desk or table top, separate from the printer. The monitor should be placed beside the processor, on the same surface. (The cartridge tape drive may be placed on top of the processor.) •...
  • Page 81 • Do not place the processor on its side, or in any other position but the upright, vertical position shown in the previous figure. • Do not place the processor or monitor on top of the printer. Installation Planning Guide...
  • Page 82: Controller Hardware Specifications And Requirements Summary

    Groupe Set board. Figure 5-5. HCU hardware (for channel-attached systems) 1. HCU 2. Table Controller hardware specifications and requirements summary The following table summarizes the specifications and electrical requirements of your DocuPrint NPS/IPS printer controller hardware components. Installation Planning Guide...
  • Page 83 “Printer specifications and requirements” chapter of this guide. Contact your service representative if you have questions not specifically addressed in this guide. Table 5-3. DocuPrint NPS/IPS printer controller specifications and power requirements: Dimensions (depth, Device width, height) Processor d=25 in.
  • Page 84 Controller specifications and requirements Table 5-4. DocuPrint NPS/IPS printer controller specifications and power requirements: Dimensions (depth, Device width, height) Processor d=17.5 in. / 44.5 cm w=17.5 in. / 44.5 cm h= 5 in. / 12.7 cm Monitor d=21 in. / 53.3 cm w=19 in.
  • Page 85: Printer Specifications And Requirements

    “Controller specifications and requirements” chapter of this guide. Power requirements Your 96/4635/180 printer has important power requirements that must be accommodated. These requirements are summarized in the table below. For further details on power requirements, refer to the voltage charts and wiring diagrams that follow.
  • Page 86: Outlet Configurations

    The following table shows the voltages for the outlets on your printing system. All power outlets must have a dedicated circuit for each system equipment piece. Make sure each power cord has a separate circuit. Table 6-2. Printer (60 Hz) voltage requirements at power outlet Service outlet configuration 4 Wire...
  • Page 87: Printer Outlet Voltages-50 Hz

    180) NEMA 14-30R Figure 6-2. 60 Hz power configuration - 30 amp (180 only) Printer outlet voltages—50 Hz All power outlets must have a dedicated circuit for each system equipment piece. Make sure each power cord has a separate circuit.
  • Page 88 240 V RMS Line 2 to neutral 240 V RMS Line 3 to neutral 240 V RMS Table 6-5. Printer (50 Hz) WYE (Star) 380 and 400 voltage Measurement Nominal Line 1 to line 2 380 V RMS Line 2 to line 3...
  • Page 89: Environmental Specifications

    Table 6-5. Printer (50 Hz) WYE (Star) 380 and 400 voltage (Continued) Service outlet configuration 5 Wire 380 V 5 Wire 380 V 5 Wire 380 V 5 Wire 400 V 5 Wire 400 V 5 Wire 400 V 5 Wire 400 V...
  • Page 90: Space Requirements

    NOTE: There must be a 78-inch / 198-cm vertical clearance throughout the entire area. Your printer must be installed in a fixed location with a minimum clearance space of 36 inches / 91.4 cm around all sides of each piece of equipment for access by service personnel.
  • Page 91: Printer Placement

    “Space planning guidelines” section of this chapter. Contact your service representative if you have questions not specifically addressed in this guide. Printer placement The following configurations are available for the Xerox 96/4635/ 180 printers: • Printer + inverter feeder/stacker (96 only) •...
  • Page 92 1. Back of system 2. Inverter 3. Feeder/stacker 4. Front of system 5. Printer 96/4635/180 printer The dimensions of the printer with the inverter feeder/stacker with inverter and feeder/stacker are as follows: feeder/stacker and one feeder/stacker Dimension Specifications Width: 151.25 inches / 384.2 cm...
  • Page 93 The following illustrates a top view of the space requirements for the printer with an inverter feeder/stacker and one feeder/ stacker. Figure 6-4. 96/4635/180 printer with inverter feeder/stacker + feeder/stacker configuration 1. Back of system 2. Inverter 3. Feeder/stacker 4. Feeder/stacker 5.
  • Page 94 Printer specifications and requirements The following illustrates a top view of the space requirements for the printer with an inverter feeder/stacker and two feeder/ stackers. Figure 6-5. 4635/180 printer with inverter feeder/stacker + feeder/stacker + feeder/stacker 1. Back of system 2.
  • Page 95 The following illustrates a top view of the space requirements for the printer with a dual feeder and stitcher/stacker configuration. Figure 6-6. 4635/180 printer with inverter feeder/stacker + feeder/stacker + feeder/stacker + feeder/stacker configuration 1. Back of system 2. Inverter 3.
  • Page 96: Bypass Transport Specifications

    Bypass transport specifications The bypass transport option enables you to add a third-party finishing device to your 96, 4635, or 180 printer. The bypass transport is installed by your service representative and remains permanently in place. You should not attempt to remove or reinstall it.
  • Page 97 Figure 6-7. Bypass transport dimensions Installation Planning Guide 6-13...
  • Page 98 Printer specifications and requirements Service access The following figure provides space planning information and service access requirements for the bypass transport from a top view. Figure 6-8. Bypass transport space planning diagram 1. Recommended third-party feeder hardware attaches at rear of 96/4635/180 printer.
  • Page 99 Bypass transport The following figure shows the paper path through the bypass paper path transport from a front view. Figure 6-9. Bypass transport paper path 1. Sheet path 2. Exit rolls 3. Floor Installation Planning Guide 6-15...
  • Page 100 Input enablement The following figure shows the paper path and the dimensions of dimensions the input enablement area from a printer front view. The input enablement kit supports third-party feeding devices. Figure 6-10. Input enablement paper path and dimensions 6-16...
  • Page 101: Configuration Diagrams With Bypass Transport

    96, 4635, and 180 with a bypass transport. These diagrams represent top views of the components, surrounded by the minimum access space requirements on all sides. Figure 6-11. 96 printer—inverter feeder/stacker-only configuration with bypass transport 1. Back of system 2. Inverter 3.
  • Page 102 Printer specifications and requirements Figure 6-12. 96/4635/180 printer—inverter feeder/stacker + feeder/stacker configuration with bypass transport 1. Back of system 2. Inverter 3. Feeder/stacker 4. Feeder/stacker 5. Bypass transport 6. Front of system 7. Printer 6-18 Installation Planning Guide...
  • Page 103: Space Planning Guidelines

    To ensure all of the space requirements are met, it is important to work with your Xerox representative. Installation Planning Guide 6-19...
  • Page 104: Clearance Space Requirements

    Xerox printing system. You can share the 36-inch / 91.4 cm clearance space around each component, as long as you follow these rules: •...
  • Page 105 NOTE: Finishers attached to your bypass transport and feeders attached to your DocuPrint 4635, 96, or 180 printer through the input enablement device may occupy shared space with Xerox equipment. However, they must be removable to allow servicing of the DocuPrint 4635, 96, or 180 printer feeders and stackers.
  • Page 106 The printers share 12 inches / 30.5 cm of the general service space, but not the exclusive operator area in front of each printer. Therefore, the printers should be separated by 24 inches / 61 cm, plus 24 inches / 61 cm, plus 12 inches / 30.5 cm. This allows for the entire operator space for each printer, plus the shared general service area of 12 inches / 30.5 cm.
  • Page 107 Between them is 60 inches / 152.4 cm of space. This allows for 24 inches / 61 cm of operator space in front of the printer facing toward the other, plus 36 inches / 91.4 cm of service space behind the printer facing away from the other.
  • Page 108: Floor Leveling

    If you do not have the leveling kit (the printer in its initial location did not require it), and you need one to level the printer in a new location, contact your Xerox site representative to obtain one. Delivery access requirements It is easy to overlook the path required to move the equipment from the truck to the operation site.
  • Page 109: Turning Radius

    Turning radius You must also consider the width of the passageway when the equipment must negotiate a corner, whether into a room, an elevator, or another passageway. There are L-shaped turns and T-shaped turns. The diagrams and the tables that follow show the minimum space required to maneuver through the turns.
  • Page 110 Passage B, depending on the type of turn the equipment must negotiate. Turning radius for The 96, 4635 or 180 is delivered with the printer, inverter feeder/ printer with stacker, and each feeder/stacker as separate modules. If separated...
  • Page 111 Table 6-8. Turning radius for printer (separated and upended on dolly) Turning radius for The following table lists the turning requirements for the printer unseparated when attached to the paper handling module (not separated). printer Table 6-9. Turning radius for printer (not separated)
  • Page 112: Printer Hardware Specifications And Requirements Summary

    NOTE: These turning figures are based on inverter/feeder/ stacker dimensions of 28 inches / 71.1 cm by 32.25 inches / 81.9 Printer hardware specifications and requirements summary The following table summarizes the specifications and electrical requirements of your printer hardware components.
  • Page 113 Table 6-12. Printer specifications and power requirements—96/4635/180 Dimensions (depth, Device width, height) 96 printer: d=38.8 in. / 98.6 cm Inverter feeder / w=119 in./ 302.3 cm stacker only h= 59.6 in. / 151.3 cm Total space required (+ access): 191 in. w by 114 in.
  • Page 114 Printer specifications and requirements Table 6-12. Printer specifications and power requirements—96/4635/180 (Continued) Dimensions (depth, Device width, height) 4635/180 d=38.8 in. / 98.6 cm printer: w=183.5 in./ 466.1cm Inverter feeder / h=59.6. in. / 151.3 cm stacker + two feeder / stackers...
  • Page 115: Space Planning Templates

    Xerox representative, to ensure that all of your space requirements are met. Installation Planning Guide...
  • Page 116 Printer specifications and requirements 6-32 Installation Planning Guide...
  • Page 117 Installation Planning Guide 6-33...
  • Page 118 Printer specifications and requirements 6-34 Installation Planning Guide...
  • Page 119 Installation Planning Guide 6-35...
  • Page 120 Printer specifications and requirements 6-36 Installation Planning Guide...
  • Page 121 Installation Planning Guide 6-37...
  • Page 122 Printer specifications and requirements 6-38 Installation Planning Guide...
  • Page 123 GRID PATTERN 1/4 inch represents one foot...
  • Page 125: System Connections

    This chapter provides cable requirements for your 96/4635/180 system. To ensure all of your cable requirements are met, it is important to work with your Xerox representative. Cable lengths Cable lengths are important considerations in planning your layout, as components can be separated only up to the length of the data interface cables that connect them.
  • Page 126: Cable Locations

    The following diagrams show those locations (marked with an X). All power cords attach to the back of the printer. Listed below are the distances of the printer power cord attachments from the left end of the printer as you face it.
  • Page 127: Installation

    This chapter describes the activities performed by you and Xerox during the installation of the Xerox DocuPrint 96/4635/180 NPS/ IPS and Xerox DocuPrint 96/4635/180 MICR NPS/IPS hardware and software components. Before installation can begin, you must complete the tasks described in the “Preparing for installation”...
  • Page 128: Your Responsibilities

    Xerox DocuPrint NPS/IPS Guide to Configuring and Managing the System for information on modifying the printcap file. 5. Xerox personnel tests the system and runs sample jobs (30 minutes). 6. Xerox personnel conducts initial operations training (2 to 4 hours).
  • Page 129: Defining The Ips Printer To The Host

    The required information and configuration procedures differ according to your connectivity type (channel or TCP/IP), and your host and PSF environment. You will need to provide these parameters to your Xerox representative on installation day. Installation Planning Guide...
  • Page 130: Software Licensing

    Guide to Configuring and Managing the System Ongoing maintenance After the installation of your Xerox DocuPrint NPS, there are a few ongoing tasks that must be performed. These tasks may include the following:...
  • Page 131: Routine Maintenance

    NOTE: Only operators who have completed the Xerox Advanced Customer Training (ACT) or eXcellerate courses or equivalent advanced customer training can replace stitcher wire. Refer to the “Xerox support services” appendix of this guide for additional information on training. Meter reading and reporting As print jobs are processed, the printer controller accumulates, saves, and maintains usage data.
  • Page 132 Installation Installation Planning Guide...
  • Page 133: Supplies

    A. Supplies This appendix provides information and specifications for the media you use with your Xerox DocuPrint 96, 4635, or 180 printer. Instructions for ordering supplies are also provided. Consumable supplies (those that are depleted during operation of the system), such as paper, dry ink, developer, fuser agent, etc., must be ordered for your printer.
  • Page 134 Use a good quality, xerographic-grade paper. For best results, weight and grade: use paper that is 20-pound or 80 gsm (grams per square meter) bond, xerographic grade. Xerox 4024 Dual Purpose Paper provides optimal performance in the printer. Refer to the consumable supplies table later in this appendix.
  • Page 135: Paper Width And Printer Performance

    The width of the paper you use for your print job is directly related to the rate at which the 96, 4635, and 180 printer can print a job. The rate at which a job prints is the throughput speed and is measured in pages per minute (ppm).
  • Page 136 Supplies The printer operates in different pitch modes. The pitch mode the printer uses for a specific print job is based on the paper size on which that job is printed. The following tables list the pitch mode boundary values, paper widths, and related printing speeds supported on the 96/4635/180 printer.
  • Page 137 Using small paper sizes in 8-pitch mode: Printing in 8-pitch mode provides the highest throughput speed available—up to 154 ppm for the 4635 printer and up to 206 ppm for the 180 printer. (The 96 printer does not support 8-pitch mode.) However, you should keep the following in mind when you...
  • Page 138 Supplies NOTE: The 96/4635/180 printer can support 14 by 17-inch / 356 by 432 mm, 20 pound or 80 gsm paper stock in 3-pitch mode. However, printing performance is not guaranteed for all types of paper of this size. Heavy (110-pound / 200 gsm) and light (16- pound / 60 gsm) large papers can cause jams throughout the system and are not recommended.
  • Page 139 US papers The following diagrams show how US Letter and US Ledger (or US Tabloid) paper sizes feed through the printer. Installation Planning Guide Figure A-3. A4 / 210 by 297 mm paper feeding (long edge feed) Figure A-4. A3 / 297 by 420 mm paper feeding (short edge feed) Figure A-5.
  • Page 140 Supplies Figure A-6. US Ledger or US Tabloid (11 by 17 inch) paper B4 papers There are two sizes of B4 paper—European or ISO (9.84 by 13.89 inches / 250 by 353 mm) and Japanese or JIS B4 (14.33 by 10.12 inches / 364 by 257 mm). European B4 feeds long edge first, while JIS B4 feeds either long edge or short edge first.
  • Page 141: Paper Care

    Plan ahead and keep at least a day’s supply of paper in the same area as the printer to allow environmental stabilization prior to printing. For more detailed information on paper for Xerox printers, refer to Helpful Facts about Paper, provided with your printer. Installation Planning Guide...
  • Page 142 Conditioning Because temperature and humidity affect paper performance in paper the printer, you need to condition paper before using it. To do this, store paper for a specified length of time in the same type of environment as your printer.
  • Page 143 The length of time you should condition your paper depends on the amount of paper and the difference between the storage and operating temperatures. Use the following chart to determine the length of time needed to condition stacked cartons of paper. NOTE: The numbers in the top two rows indicate the temperature difference between the storage area and the operating environment, not actual room temperatures.
  • Page 144: Other Supplies

    You should keep at least one extra cartridge on hand at all times. The disposable cartridges are easily changed with no mess. The consumption rate of Xerox dry ink is approximately one cartridge per 60,000 pages. Use only dry ink that is specified for use in the 96, 4635, or 180 printer, as described in the consumable supplies table.
  • Page 145: Fuser Agent

    (each box contains one bottle) on hand for installation by the service representative. The consumption rate of Xerox fuser agent is approximately one bottle per 250,000 pages. For product information, refer to the consumable supplies table in this appendix.
  • Page 146: Cartridge Tapes

    Center. Custom fonts Custom fonts and graphic images such as company logos and signatures can be digitized by the Xerox Font Center for use on your printer. Receiving fonts Fonts are received on a diskette from your local Xerox Font Center.
  • Page 147: Micr Tools

    MICR tools You can use the following tools to determine whether the MICR output is printing within MICR specifications: • MICR Positioning and Dimension Gauge. • 8 Power (X) Comparator with MICR grid. NOTE: You should use the Custom Transfer Assist Blade to ensure acceptable MICR line quality on all MICR printing systems that use nonstandard paper sizes.
  • Page 148: Consumable Supplies Tables

    Supplies Consumable supplies tables A number of supplies are available from Xerox for your DocuPrint printer. Use the following tables to help determine your supply needs. NOTE: Customers in the U. S. may use the part numbers in these tables to order supplies. Customers outside the U. S.
  • Page 149 Item 8.5 x 11 inch 8.5 x 11 inch 8.5 x 11 inch 8.5 x 14 inch 8.5 x 11 inch 8.5 x 11 inch 8.5 x 14 inch 8.5 x 11 inch 8.5 x 11 inch 8.5 x 14 inch 8.5 x 11 inch 8.5 x 11 inch 8.5 x 14 inch...
  • Page 150 2500 sheets per cartons 4024 Dual Purpose Paper, 7-hole* 2500 sheets per cartons Xerox transparencies are packaged 100 sheets to a box. Clear, with a white strip on the edge Clear, with removable strip Clear, high speed, with paper backing Xerox labels are packaged 100 sheets to a box.
  • Page 151 250 sheets each of buff, gray, goldenrod, and ivory. Installation Planning Guide Table A-5. Stocks list for 96/4635/180 printers (Continued) Description Xerox tab stock is packaged in 5-tab sets. 250 sheets per carton. Straight collated singles (forward, top down): • Non-drilled 90-pound, Index white •...
  • Page 152 Supplies Table A-6. Carbonless stocks for 96/4635/180 printers Size Parts Sequence 8.5 in. x 11 Reverse/ in. * Straight Straight/ Double Reverse/ Straight Straight Straight/ Double Straight * All papers are packaged 500 sheets per ream, with 10 reams per carton. Each ream contains only complete carbonless sets (i.e., 501 sheets in a three-part ream for 167 sets).
  • Page 153: Complete Supplies List-96/4635/180 Printers

    (i.e., 501 sheets in a three-part ream for 167 sets). Complete supplies list—96/4635/180 printers The following table lists the supplies in addition to paper that are available for your printer. Use this table to help you determine your supplies needs. Table A-7. Complete supplies list for 96/4635/180...
  • Page 154 Supplies Table A-7. Complete supplies list for 96/4635/180 (Continued) Item Description Developer Packaged 2 bottles per carton. Effective life is approximately one carton per 1,000,000 pages. (2 bottles required for replacement.) Developer, MICR Packaged 2 bottles per carton. Effective life is approximately one carton per 600,000 pages.
  • Page 155: Ordering Supplies

    You can make arrangements to receive them sooner in emergency situations. Your Xerox sales representative can help you submit the initial order of supplies needed for installation. These items include paper, dry ink, MICR dry ink, fuser agent, developer, and MICR developer.
  • Page 156 Item Description and part number Paper Transparencies A-24 an invoice, you need to provide the purchase order number to Xerox at the time you place the order. Quantity Date to order Date ordered Installation Planning Guide...
  • Page 157 Table A-8. Supplies checklist for 96/4635/180 printer (Continued) Checklist: Supplies Use this checklist to help record the supplies you require, the date on which the order should be placed, and the actual date of the order. Item Description and part number...
  • Page 158 Supplies A-26 Installation Planning Guide...
  • Page 159: Xerox Support Services

    B. Xerox support services Xerox provides many services in support of your laser printing system. This appendix contains information on the following services: • Xerox Customer Service Support Center • Xerox Printing Systems Customer Support Center • Xerox Customer Documentation Catalog •...
  • Page 160: Xerox Printing Systems Customer Support Center

    The key to effective use of the Xerox Printing Systems Customer Support Center is correct identification of the problem. Before calling the center, it is helpful to have the following information available: •...
  • Page 161: Xerox Customer Documentation Catalog

    5:00 a.m. and 5:00 p.m., Pacific time. Xerox Customer Documentation Catalog Detailed information on documentation for DocuPrint printers and other Xerox products is contained in the Xerox Customer Documentation Catalog. The catalog includes a brief description of each item and its cost.
  • Page 162: Operator Training

    Its address is: http://www.XDSS.com Operator training Operator training is conducted at your location by your Xerox system analyst or other identified representative, shortly after the printer is installed. Training takes two to four hours, depending on the system configuration.
  • Page 163: Xerox Font Center

    Xerox Font Center The Xerox Font Center can send you samples and catalogs of the fonts available for your printer. To receive font samples, obtain price information, obtain technical support, or order licensed or custom fonts, call 1-800- 445-FONT (-3668) between 6:00 a.m and 5:00 p.m. Pacific time (U. S. only).
  • Page 164 Xerox support services Installation Planning Guide...
  • Page 165: Related Publications

    C. Related publications Xerox documents The Xerox DocuPrint NPS/IPS documentation set includes the documents listed below. • Guide to Configuring and Managing the System • Guide to Managing Print Jobs • Guide to Performing Routine Maintenance • Guide to Submitting Jobs from the Client •...
  • Page 166: Ibm Reference Manuals

    Mixed Object Document Content Architecture Reference (SC31-6802-04) describes the functions and elements that make up MO:DCA data streams. • Page Printer Formatting Aid/370: User’s Guide (S544-5284- 03) contains information about the PPFA product that is used to create AFP page definitions and form definitions. •...
  • Page 167 • Advanced Function Presentation: Printer Summary (G544- 3135-10) contains detailed characteristics of IBM’s page printers. • Advanced Function Presentation Workbench for Windows: Using the Viewer Application (G544-3813-00) contains information about using this product with the AFP application programming interface. •...
  • Page 168 • IBM InfoPrint Manager for AIX: PSF Direct (S544-5486-00) provides information about using InfoPrint Manager for AIX. Refer to the “Xerox support services” appendix of this guide for information on how to order these and other publications. Installation Planning Guide...
  • Page 169: Docuprint Nps/Ips On A Novell Network

    Novell NetWare software receives and queues print jobs. It assigns priorities to incoming jobs and tracks information about each job. It sends print jobs to the printer, and contains a series of utilities and menus to set up, manage, and manipulate print queues.
  • Page 170: Queue To Printer Relationships

    Novell NetWare allows for flexibility in setting up different printing configurations. Multiple queues and printers can be associated in different ways to meet different needs, such as the following: • One queue to one printer • Multiple queues to one printer •...
  • Page 171: Print Server (Pserver

    DocuPrint NPS/IPS through an NCP/IPX connection. Once the job is sent to the printer, the job is deleted from the print queue, and the file removed from the queue directory.
  • Page 172: Job Parameters

    The form name can have a maximum of twelve characters, and the first character must be alphabetic. If a form name is not used, a virtual printer with the same name as the queue is used. Forms are defined on the Novell server using the Novell PRINTDEF program.
  • Page 173: Remote Printer (Rprinter

    A Novell remote printer workstation (DocuPrint NPS/IPS Printer Controller) is a vehicle for the print server to move print data to a printer that is not directly connected to the print server. The remote printer software runs on a workstation that connects to a remote printer through a parallel or serial port.
  • Page 174 Novell forms. The administrator uses the PRINTDEF program to create forms with the same name as DocuPrint NPS/IPS virtual printers. Users then select a virtual printer by selecting a form with the same name using the User Tools program in the NetWare Tools folder of Windows, or the -F option in the DOS CAPTURE command.
  • Page 175 RPRINTER does not require that unencrypted logins be permitted. The following table lists the differences between DocuPrint NPS/ IPS as a print server or as a remote printer. Table D-1. Print server and remote printer differences DocuPrint NPS/IPS as a PSERVER Functions like a Novell print server.
  • Page 176: Novell Configuration

    Enter any name (for example, Gazette) for the printer. e. Select Remote Other/Unknown type for the printer and f. Define the printer in the Queue Service by highlighting the g. Press the Insert key to select the Print Queue (for h.
  • Page 177 2 of this guide to your service representative. In the following illustration, the queue, virtual printer, and specified form are configured with the same name. The user sends a print job that specifies a print queue named Gazette through the Ethernet or Token Ring port to the Gazette queue that is served by the print server.
  • Page 178: Configuring Docuprint As An Rprinter

    From the Print Server window, configure a printer for d. Type any name (for example, Gazette) for the printer. e. Define the printer in the Queue Service by highlighting the f. Press the Insert key to select the Print Queue (for g.
  • Page 179 Select Option 3, enter <N> to the Review All d. Enter the following information: e. Save all of the options. 4. Enter Create Virtual Printer Gazette (must be the same name as the PSERVER printer name). 5. Enter Start All.
  • Page 180: Supporting Docuprint Nps/Ips On The File Server

    In the following illustration, the queue, remote printer, and virtual printer are configured with the same name, and the specified printer is set to print duplex. The user sends a print job through the LPT1 port to a queue named DPDuplex that is sent to the DPDuplex, and assigned to DPDuplex virtual printer.
  • Page 181 NOTE: DocuPrint NPS/IPS supports native connection to Novell 3.12 file servers. However, to run DocuPrint NPS/IPS with Novell 4.X servers, the Novell server must be configured to Bindery Emulation. Installation Planning Guide D-13...
  • Page 182 DocuPrint NPS/IPS on a Novell network D-14 Installation Planning Guide...
  • Page 183: Defining The Channel-Attached Printer To The Host

    This appendix contains some explanations and sample printer parameters for defining a channel-attached printer to your host, in each PSF environment. MVS parameters This section gives examples of printer device parameters and definitions in the MVS mainframe environment using PSF/MVS.
  • Page 184 PSF definitions //PRT6 CNTL //PRT6 PRINTDEV FONTDD=*.FONT300, //PRT6 ENDCNTL Device definitions The following are examples of MVS hardware configuration definition (HCD) printer definition panels. This defines the physical device. Figure E-1. MVS hardware configuration definition panels FONT240=*.FONT240, FONT300=*.FONT300, FDEFDD=*.FDEF, PDEFDD=*.PDEF, OVLYDD=*.OLAY,...
  • Page 185 Figure E-2. MVS hardware configuration definition panels Figure E-3. MVS hardware configuration definition panels For further information on defining your printer, refer to the following IBM documentation. • OS/390 Hardware Configuration Definition User’s Guide (#SC28-1848) • 2/OS Hardware Configuration Definition User’s Guide...
  • Page 186: Infoprint Manager Procedures For Windows Nt And Windows 2000

    (physical printer) using Infoprint Manager for Windows NT and Windows 2000. To create a channel-attached printer: 1. On the menu bar, click Printer, then Create, then PSF, then Channel. NOTE: The Channel is not shown in the menu by default. To add it, select Printer, then Add/Remove Menu Items.
  • Page 187: Infoprint Manager Procedures For Aix

    This is a graphical user interface (GUI) supported by Infoprint Manager for AIX versions 3.1 and 3.2 only. NOTE: Regardless of the method used, from the Model pulldown menu, make sure to select Infoprint 60 as your printer model. For detailed information on setting the attribute default values using any of these methods, refer to the appropriate section of the document, IBM Infoprint Manager for AIX, Getting Started.
  • Page 188: Vm Sample Definitions

    Defining the channel-attached printer to the host VM sample definitions This section gives an example of printer device parameters and definitions for a channel-attached printer in a mainframe VM environment using PSF/VM. CNTLUNIT CUNMBR=632, PATH=16, PRTOCL=S, SHARED=N, UNIT=AFP1, UNITADD=((32,02)) IODEVICE CUNMBR=632,...
  • Page 189: Vse Sample Definitions

    VSE sample definitions This section shows sample parameters for a channel-attached printer in a mainframe VSE environment, using PSF/VSE. * $$ JOB JNH=APSTANO,DISP=L,PRI=3,CLASS=B * $$ LST CLASS=A,DISP=0,PRI=9 // JOB APSTANO // OPTION NODUMP // DLBL IMSYS ‘IMSYS’ // EXTENT ,SYSWK6 // DLBL IMSYS ‘IMSYS’...
  • Page 190 Defining the channel-attached printer to the host Installation Planning Guide...
  • Page 191: Defining The Printer To The Host: Tcp/Ip Attachment

    PSF environment. MVS or OS/390 parameters This section discusses the parameters and procedures required to define a printer to your host, followed by examples of the parameters required for a Token Ring connection using TCP/IP in a MVS environment.
  • Page 192: Network Configurations - Mvs

    Remote LAN environment in which there are data communication links between the host and the LAN-attached controller • Configurations in which the LAN with the printer attached is connected to the host-attached controller using LAN devices such as routers •...
  • Page 193 This section discusses the procedures for configuring the printer in JES2 or JES3 environments. Configuring in To configure the PSF printer in JES2, follow these steps: JES2 1. Locate the JES2 initialization dataset in the JES2 Startup JCL Procedure (JES2 PROC). (This is normally kept in SYS1.PROCLIB, although your system may use a different...
  • Page 194 Defining the printer to the host: TCP/IP attachment Table F-1. JES2 FSS statement parameters (Continued) Item Source of description Default value HASPFSSM HASPFS JES2 Load module to be loaded into FSS address space PRT parameters QUEUE None Installation output class...
  • Page 195 PRT0001 CLASS=E,FSS=FSS1,MODE=FSS,PRESELCT=YES, START=NO,TRKCELL=YES,WS=(Q) Configuring in Follow these steps to configure the PSF printer in JES3: JES3 1. Locate the JES3 initialization dataset (commonly known as Initialization Deck) in the JES3 catalogued JCL Procedure. (This is normally kept in SYS1.PROCLIB, although your system may use a different library.)
  • Page 196 Defining the printer to the host: TCP/IP attachment • The following table lists the JES3 FSS statement parameters to be defined. Table F-3. JES3 FSS statement parameters Item Source of description Default value FSSDEF parameters FSSNAME None Installation preferences MSGDEST...
  • Page 197 Must be FSS. Installation Planning Guide Range of acceptable values Comments N or J or C C: printer will offset- stack or stitch on a dataset copy basis. J: Printer is to increment offset stacking or stitching on a job boundary.
  • Page 198 Defining the printer to the host: TCP/IP attachment Table F-3. JES3 FSS statement parameters (Continued) Item Source of description Default value Any class Installation selected output class standards Installation preferences (see note) NOTE: The WS parameter CL specifies that datasets with the same class as the WS parameter should be selected.
  • Page 199 FSSDEF statement PNAME parameter in JES3. See the appropriate section in this appendix for clarification). 2. Add a PRINTDEV statement to define the printer in PSF. (See the example below for the general format or the Print Services Facility for OS/390 Customization for more information.)
  • Page 200 Defining the printer to the host: TCP/IP attachment Table F-5. PSF/MVS PRINTDEV statement parameters (Continued) Item Source of description Default value FORMDEF None Installation preferences IPADDR None Xerox installation JOBHDR None Installation preferences JOBTRLR None Installation preferences LOGMODE LUNAME MESSAGE...
  • Page 201 Comments Not applicable for TCP/ IP-attached printers Name of font library DD statement. Fonts in this library must match the resolution the printer is using. Name of default Page Definition for printer Name of Page Definition library DD statement (YES,nnn) or...
  • Page 202 FORMS specification different from job previously printed. This is recommended where there are multiple paper stocks for use on the printer. Not applicable to Xerox cut-sheet printers IDLE, TIME, or Not applicable to Xerox NONE cut-sheet printers REDRIVE or REDRIVE: When there is...
  • Page 203 TRACE=NO /* BUILD INTERNAL TRACE @H3C*/ // PRT277 ENDCNTL 5. Configure TCP/IP for MVS for the printer NOTE: The information in this section is for TCP version 3.2 and 3.3. For version 3.4 or later, refer to the appropriate IBM documentation.
  • Page 204 Defining the printer to the host: TCP/IP attachment NOTE: It is not necessary to define the printer in TCP/IP for MVS, because the printer acts as a conduit from the MVS system to the LAN. However, some settings in the TCP/IP Profile dataset may need to be altered, depending on your current settings.
  • Page 205 Reference.) • KEEPALIVEOPTIONS statement: PSF relies on TCP to detect when a connection with the printer is no longer usable. When no data has been exchanged between PSF and its connection partner, TCP sends keep-alive probes to the connection partner periodically. These periodic probes, called...
  • Page 206 Defining the printer to the host: TCP/IP attachment Table F-8. TCP/IP Profile dataset statements example – MVS ACBPOOLSIZE ADDRESSTRANSLATIONPOOLSIZE CCBPOOLSIZE DATABUFFERPOOLSIZE ENVELOPEPOOLSIZE IPROUTPOOLSIZE LARGEENVELOPEPOOLSIZE RCBPOOLSIZE SCBPOOLSIZE SKCBPOOLSIZE SMALLDATABUFFERPOOLSIZE TCBPOOLSIZE TINYDATABUFFERPOOLSIZE UCBPOOLSIZE KEEPALIVEOPTIONS INTERVAL 10 SENDGARBAGE TRUE ENDKEEPALIVEOPTIONS GATEWAY ; * Network...
  • Page 207 6. Test the printer to ensure it prints from the MVS host Test the printer by one of the following methods: • Send a job from the host through PSF to print on the printer. • Ping the printer from your MVS host to ensure MVS can establish a connection with the TCP/IP-attached printer.
  • Page 208 There is proper connectivity to the Multi-station Access Unit (MAU), if one is being used. • The IP address used to define the printer in PSF is unique in the TCP/IP network. • The IP address of the MVS system is unique. If not, consult your network administrator to resolve the address problem.
  • Page 209: Correcting For Printer Performance Issues - Mvs

    If the printer is on a LAN that also has a large number of other devices attached to it, the high levels of traffic on the LAN can cause printer speed degradation. Consider moving the printer to a LAN that does not have so much activity on it.
  • Page 210: References - Mvs

    Defining the printer to the host: TCP/IP attachment References – MVS The following IBM documents, referenced in this section, can provide additional information on MVS-to-IPDS printer connectivity. Title MVS Collection Online Library Omnibus Edition OS/390 HCD Planning or MVS/ESA Migration Planning: Dynamic I/O Configuration OS/390 HCD User’s Guide or MVS/ESA Hardware Configuration: Using the Dialog...
  • Page 211: As/400 Parameters

    V3R2 5763TC11 V3R2 5763AF1 Network configurations – AS/400 The printer is supported in all the following types of AS/400 configurations, provided that the software prerequisites are installed. • Basic configuration in which the AS/400 is attached to a LAN using either a Token Ring or Ethernet network adapter card •...
  • Page 212: Configuration Steps - As/400

    Configuration steps – AS/400 Follow these steps to configure your AS/400 to print to a printer connected to the LAN, using TCP/IP. Configuration The following worksheet will help you in planning the printer worksheet installation.
  • Page 213 2. Create the PSF/400 configuration Follow these steps to configure PSF/400 for the printer. 1. At the AS/400, press <F4> to prompt the CRTPSFCFG command. 2. Key in the parameter values as indicated in the figure below. For parameters with * beside them, refer to the configuration worksheet, earlier in this section.
  • Page 214 Defining the printer to the host: TCP/IP attachment 3. Create the printer device description – AS/400 Follow these steps to create the device description for the printer. 1. At the AS/400, press <F4> to prompt the CRTDEVPRT command. 2. Key in the parameter values as indicated in the appropriate figure below.
  • Page 215 LIBRARY... TEXT ‘DESCRIPTION’... 4. Test the printer connection – AS/400 Test the printer by one of the following methods to ensure AS/ 400 is able to make a connection with the printer: • Send a job from the host through PSF to print.
  • Page 216 Defining the printer to the host: TCP/IP attachment Pinging the printer To ping the printer to verify a connection can be made, enter the following command on an OS/400 command line: PING ‘Remote Location’ ‘remote location’ specifies the internet protocol (IP) address of the printer (refer to the configuration worksheet, earlier in this section).
  • Page 217 There is proper connectivity to the Multi-station Access Unit (MAU), if one is being used. • The IP address used to define the printer in PSF is unique in the TCP/IP network. • The IP address of the AS/400 system is unique. If not, consult your network administrator to resolve the address problem.
  • Page 218: Correcting For Printer Performance Issues - As/400

    OS/400 Work Management F-28 problems If the printer is on a LAN that also has a large number of other devices attached to it, the high levels of traffic on the LAN can cause printer speed degradation. Consider moving the printer to a LAN that does not have so much activity on it.
  • Page 219: Infoprint Manager Procedures For Windows Nt And Windows 2000

    (physical printer) using Infoprint Manager for Windows NT and Windows 2000. To create a PSF TCP/IP printer: 1. On the menu bar, click Printer, then Create, then PSF, then TCP/IP. NOTE: If the TCP/IP is not shown in the menu, add it by selecting Printer, then Add/Remove Menu Items.
  • Page 220: Infoprint Manager Procedures For Aix

    This is a graphical user interface (GUI) supported by Infoprint Manager for AIX versions 3.1 and 3.2 only. NOTE: Regardless of the method used, from the Model pulldown menu, make sure to select Infoprint 60 as your printer model. For detailed information on setting the attribute default values using any of these methods, refer to the appropriate section of the document, IBM Infoprint Manager for AIX, Getting Started.
  • Page 221: Glossary

    Glossary This glossary contains a list of terms for working with the Xerox DocuPrint NPS/IPS printing system, and a definition of each. Paper size measuring 297 by 420 mm. Paper size measuring 210 by 297 mm. American Standard 7-bit code which represents alphanumeric information.
  • Page 222 Glossary binary digit (bit) In the binary numbering system, either of the characters 0 or 1. The bit is the basic unit of information with which a computer works. It can take the form of a magnetized spot, an electric pulse, a positive or negative charge, etc.
  • Page 223 (2) for adjusting differences of speed between devices, or between a device and a communicating facility. bypass transport Optional module that moves paper from the printer to a finishing device. byte Fixed number of bits (in data processing, usually 8) operated upon as a unit.
  • Page 224 Glossary client software Software that manages the submission of print jobs to the Printer Controller. client workstation Workstation connected to the network used to create print jobs (documents) and submit them to the printer controller. command Statement entered that instructs the system to perform an operation.
  • Page 225 Unit). Document Feeding and Finishing Architecture. Software that enables third-party feeding and finishing devices to be attached to a Xerox printer to perform pre- and post-processing functions (such as roll-feeding, saddle-stitching, booklet-making, etc.) diagnostics Programs used to diagnose problems within the system or to help service personnel pinpoint the source of such problems.
  • Page 226 Hardware devices or software packages that allow the printer to perform as specified. Ethernet Network standard consisting of a coaxial cable or twisted pair and associated components for connecting workstations to each other, to file servers, and to peripherals.
  • Page 227 3. To prepare the surface of a disk for acceptance of data. form feed Keyboard/printer control character that causes the printer to skip the top of the next page. forms source library. Uncompiled collection of user-created files containing FDL commands. Refer to FDL; form.
  • Page 228 Process of installing system hardware and software. Also the process of converting a design into an actual working system. impressions per The number of pages (one side) a printer can print during the minute (ipm) space of one minute. Used interchangeably with pages per minute (ppm).
  • Page 229 Internet Protocol Refers to an address of any host that uses TCP/IP network (IP) address protocol. Image Output Terminal. See printer. job descriptor entry. Collection of job descriptions. See also job; JSL. job descriptor library. Collection of compiled job descriptions.
  • Page 230 A logical page is defined by an origin location, thus allowing more than one logical page to be placed on a physical page. long-edge feed The movement of paper through the printer in the direction of the (LEF) paper length (the longer side of a sheet of paper). See also short-edge feed.
  • Page 231 network 1. System of geographically separate computers, linked to one another over transmission lines. 2. Communication lines connecting a computer to its remote terminals. node Station, terminal, or computer that performs some control operation and influences the operation of the network as a whole.
  • Page 232 Set of attributes available for controlling the processing of a print job. Print attributes include simplex or duplex printing, media selection, collating, stitching, and so on. Print attributes can be sent to the Printer Controller as part of the job, providing automatic job processing. printer...
  • Page 233 99 records in a sequential file-access file have to be read before the 100th record is accessible. short-edge feed The movement of paper through the printer in the direction of the (SEF) paper width (the shorter side of a sheet of paper).
  • Page 234 Glossary string Connected sequence of alphanumeric characters treated as one unit of data by a program. SunOS Operating system developed primarily by Sun Microsystems for use on Sun computers and workstations. SunOS provides inherent support for UNIX and for TCP/IP. syntax Rules governing the structure of expressions in a programming language.
  • Page 235 Page area selected by a forms designer for printing. virtual printers Alternate names for the printer which allow different sets of default attributes to be applied to submitted jobs. The operator and system administrator define virtual printer names and the associated set of attributes and values.
  • Page 236 Glossary Glossary-16 Installation Planning Guide...
  • Page 237 4-11 lpr 4-11 status 4-11 UNIX command tool 4-11 components DocuPrint system 1-10 hardware 5-8 printer controller 2-1 printing system 1-10 conditioning paper A-10 configuration, network 1-12 connectivity boards 2-5 consumable supplies table A-16 control panel HCF feeder tray 3-2...
  • Page 238 INDEX customer responsibilities 1-13, 4-2–4-4, 8-2– data cables 7-1 Data Control Interface Module (DCIM2) card data streams 1-9 default router 4-10 definitions, see sample printer definitions delivery requirements 6-24–6-28 DELTA configurations 6-4 developer A-13, A-22 devices, input enablement 6-21 dimensions bypass transport 6-12 printers 6-7–6-11...
  • Page 239 8-1 network checklist 4-9–4-15 planning checklist 4-4–4-8 preparation 4-1–4-15 process 8-1–8-2 timeframes 4-5 Xerox responsibilities 4-2 inverter feeder/stacker module 3-1, 3-3 IOCA (Image Object Content Architecture) address 4-9 broadcast address 4-10 Netmask 4-9 IPDS data streams 1-9 IPX internal network number, specifying...
  • Page 240 1-1 components attention light 3-1, 3-5 high-capacity feeder 3-3 high-capacity stacker 3-4 inverter feeder/stacker module 3-1, printer control console 3-6 processor feeder trays 3-2 purge tray 3-1, 3-5 sample tray 3-1 configurations 3-8–3-10 paper path 3-10 processor 2-2, 2-6, 5-9, 5-10...
  • Page 241 5-1–5-3, 5-9, 6-1–6-5, 6-28–6-30 printer controller space 5-8 site 4-6 space 5-3, 6-6, 6-19–6-28 Token Ring 4-16 responsibilities customer 1-13, 4-2–4-4, 8-2–8-3 Xerox 1-13, 4-1–4-2, 8-2–8-3 retry count 4-11 root password 4-10 router, default 4-10 RPRINTER D-5 safety hotline numbers xi laser ix operation x–xiii...
  • Page 242 F-1 Ethernet interface 1-6 configuring F-13 Profile dataset F-14–F-16 telephone numbers service B-2 Xerox Parts and Product Support Center A-23 throughput speed 1-2 time requirements, planning installation 4-5 tinted paper A-3 Token Ring 1-6, 1-11, 2-5, 4-16 toner, see dry ink...
