Space planning templates

Installation Planning Guide
The dimensions and space requirements for your printer
components are provided earlier in this chapter. The space
planning templates are designed to simplify the space planning
process by helping you to create a floor plan for your base
components, particularly if you have shared clearance space.
The easiest way to use the space planning templates is to move
the templates around on the grid located at the end of this
section and determine the optimum placement for your printer
components. Make sure to consider other pieces of equipment,
such as cabinets, tables, and optional equipment when planning
your space. Your customer support representative can help you
plan space for additional components.
The templates are to scale with the grid; each square is equal to
12 by 12 inches/30.5 by 30.5 cm. The curved dotted lines in the
corners of the space perimeters indicate the corners that may be
rounded off while still maintaining the required clearance space.
There are a number of factors to keep in mind when planning
your site, including the following:
Clearance space requirements
Cable length.
Refer to these sections in this manual when considering the
various factors involved in planning the appropriate location for
your printing system.
When determining your space requirements, remember to
consider all of the components you plan to have installed. If you
have a bypass transport or input enablement device option on
your printing system, you should contact the sales
representatives for the company from which you purchased your
finishers and feeders, as well as your Xerox representative, to
ensure that all of your space requirements are met.
6-31
