Printer placement

96 printer with
inverter feeder/
stacker only
Installation Planning Guide
For information on clearance space and other space planning
considerations, refer to the "Space planning guidelines" section
of this chapter. Contact your service representative if you have
questions not specifically addressed in this guide.
The following configurations are available for the Xerox 96/4635/
180 printers:
Printer + inverter feeder/stacker (96 only)
Printer + inverter feeder/stacker + feeder/stacker
Printer + inverter feeder/stacker + feeder/stacker + feeder/
stacker (4635 and 180 only)
Printer + inverter feeder/stacker + feeder/stacker + feeder/
stacker + feeder/stacker (4635 and 180 only).
Measurements and a top-view diagram for each of these
configurations is provided on the following pages.
The dimensions of the printer with the inverter feeder/stacker-
only configuration are as follows:
Dimension
Width:
Depth:
Height:
Total weight:
Total space requirement:
Specifications
119 inches / 302.3 cm
38.8 inches / 98.6 cm
59.6 inches / 151.3 cm
1404 pounds / 6370 kg
191 by 114 inches /
567 by 290.3 cm
6-7
