Printer specifications and requirements

Outlet configurations

Printer outlet voltages—60 Hz
Service outlet
configuration
4 Wire
4 Wire
4 Wire
4 Wire
4 Wire
Printer power
outlet/cord voltage
configurations—
60 Hz
6-2
Agency certification: UL 478 and 1950, IEC 950, CE Mark,
CSA 22.2 #220-1986, FCC (Class A), and VDE 0871 (Class A).
This section discusses specifications for system outlets and the
required wall outlet configurations for the USA / Canada and
internationally.
NOTE: All power outlets must be dedicated to this equipment.
When determining the electrical connections for your printer,
make sure that:
•
Each power cord has a separate circuit
•
The printer power cord configurations match your receptacle
•
Your electrical outlets are within the required specifications.
50 Hz systems: Ensure that power connections are per local
codes/regulations.
The following table shows the voltages for the outlets on your
printing system. All power outlets must have a dedicated circuit
for each system equipment piece. Make sure each power cord
has a separate circuit.
Table 6-2. Printer (60 Hz) voltage requirements at power outlet
Measurement of wiring
Line 1 to neutral
Line 2 to neutral
Neutral to ground
Line 1 to line 2
Line 1 to line 2
The following figures shows the 60 Hz power outlet configuration
for 50 amp NEMA 14-50R (96, 4635, and 180) and 30 amp
NEMA 14-30R (180 only). Voltage to ground is shown for
troubleshooting purposes.
Nominal
Range
120 V RMS
107-127 V RMS
120 V RMS
107-127 V RMS
0
0-10 V RMS
208 V RMS
182-220 V RMS
240 V RMS
210-254 V RMS
Installation Planning Guide
