IPX internal
network number
LAN network
number
Network framing
type
Installation Planning Guide

DocuPrint NPS/IPS as a remote printer (RPRINTER)

Provide the following information to the service representative if
you configure DocuPrint NPS/IPS as a remote printer on the
Novell network (for further information, refer to the "Installation
process" section in the "Installation" chapter of this guide):
• Novell print server name: Indicates the name of the print
server to which the DocuPrint NPS/IPS will connect. An
advertising print server with this name must be running on
the Novell internet.
• Printer names to service: Refers to the name or names of
the printers defined for the Novell print server. Virtual printers
should be defined with these names after DocuPrint NPS/IPS
installation is complete. These printers should be defined as
type Remote Other/Unknown.
Specify the network number for the internal IPX network in the
DocuPrint server. This number must be globally unique within
the NetWare internet to which the DocuPrint NPS/IPS is
connected. (Do not assign a number that is used by other
machines to which the DocuPrint NPS/IPS will be connected.)
Specify the network number for the cabling system to which the
DocuPrint NPS/IPS is connected, for example the Ethernet or
Token Ring segment.
Specify the network framing type used for IPX/SPX
communication by DocuPrint NPS/IPS. There are eight options:
• ETHERNET__II
• ETHERNET__802.3
• ETHERNET__802.2
• ETHERNET__SNAP
• TOKENRING
• TOKENRING__SNAP
• FDDI
• FDDI__SNAP.
4-13
