Printer specifications and requirements

Bypass transport specifications

Dimensions
6-12
The bypass transport option enables you to add a third-party
finishing device to your 96, 4635, or 180 printer. The bypass
transport is installed by your service representative and remains
permanently in place. You should not attempt to remove or
reinstall it. The following is supported by the bypass transport:
•
Paper size and weight: You can use all of the paper sizes
and weights supported on the 96/4635/180 in the bypass
transport.
•
Sheet exit orientation: 1 to N (the same order in which
sheets are fed from the printer), delivered face down.
•
Maximum throughput speed: The bypass transport for the
96 and 135 printer supports throughput speeds of up to 139
ppm (pages per minute). The 180 bypass transport supports
speeds up to 180 ppm. (These rates are based on stocks up
to 9 by 14.33 / 229 by 364 mm in length.)
•
Sheet exit height: 34 inches / 86 cm above the floor.
The following figure shows the dimensions of the bypass
transport in millimeters and inches from the right end view.
