//PRT277 CNTL
//PRT277 PRINTDEV FONTDD=*.FONT01, /* FONT LIBRARY DD */
//
//
//
//
//
//
//
//
//
//
//
//
//
//
//
//
//
//
// PRT277 ENDCNTL
Installation Planning Guide
If this parameter is not coded, PSF uses the default name,
TCPIP. (For a full description of the PARM parameter, refer to
Print Services Facility for OS/390 Customization.)
Table F-6. PSF/MVS PRINTDEV statement example
OVLYDD=*.OLAY01, /* OVERLAY LIBRARY DD */
IPADDR='13.240.160.97',
PORTNO=5005
PSEGDD=*.PSEG01, /* SEGMENT LIBRARY DD */
PDEFDD=*.PDEF01, /* PAGEDEF LIBRARY DD */
FDEFDD=*.FDEF01, /* FORMDEF LIBRARY DD */
JOBHDR=*.JOBHDR, /* JOB HEADER SEPARATOR OUTPUT */
JOBTRLR=*.JOBTLR, /* JOB TRAILER SEPARATOR OUTPUT */
DSHDR=*.DSHDR, /* DATA SET HEADER SEPARATOR */
MESSAGE=*.MSGDS, /* MESSAGE DATA SET OUTPUT */
BUFNO=29, /* NUMBER OF WRITE DATA BUFFERS */
PAGEDEF=X06483, /* DEVICE PAGEDEF DEFAULT */
FORMDEF=A10111, /* DEVICE FORMDEF DEFAULT @H3C*/
CHARS=(GT15, /* DEVICE */
GT12,GT18,GT24), /* DEFAULT FONT SET @H3C*/
PIMSG= (YES,999), /* ACCUMULATE DATA SET MESSAGES */
DATACK=BLOCK, /* BLOCK DATA CHECKS */
TRACE=NO /* BUILD INTERNAL TRACE @H3C*/
5. Configure TCP/IP for MVS for the printer
NOTE: The information in this section is for TCP version 3.2 and
3.3. For version 3.4 or later, refer to the appropriate IBM
documentation.
The TCP/IP Profile dataset contains statements that define the
parameters used by TCP/IP for MVS address space. The
following parameters have special consideration for PSF and the
TCP/IP-attached printers.
/* PRINTER IP ADDRESS */
/* PORT NUMBER */
F-13
