VLT® Servo Drive System ISD 511
Operating Guide
Subtool
CAM editor
Configuration parameter
Drive commissioning
The detailed description of the VLT
System ISD 510, DSD 510, MSD 510 (VLT® FlexMotion

6.6.2 System Requirements

To install the VLT Servo Toolbox software, the PC must meet the following requirements:
®
• Supported hardware platforms: 32-bit, 64-bit.
• Supported operating systems: Windows 10, Windows 11.
• .NET framework version: 4.7.
• Minimum hardware requirements: 512 MB RAM, Intel Pentium 4 with 2.6 GHz or equivalent, 100 MB hard disk space.
• Recommended hardware requirements: Minimum 1 GB RAM, Intel Core i5/i7 or compatible.
6.6.3 Installing the VLT® Servo Toolbox Software
Administrator rights are required to install the software with the Windows operating system. If necessary, contact your system ad-
ministrator.
Procedure
1. Check that your system meets the system requirements specified in
2. Download the VLT
®
3. Right-click on the .exe file and select Run as administrator.
4. Follow the on-screen instructions to complete the installation process.
6.6.4 VLT® Servo Toolbox Communication

6.6.4.1 Overview

This chapter describes the Ethernet-specific network interface settings needed by the VLT
munication methods: direct communication and indirect communication. Their particular network settings are described in the re-
spective subchapters.
Read and perform the steps with care. Incorrect network configurations can lead to loss of connectivity of a network interface.

6.6.4.2 Firewall

Depending on the firewall settings and the fieldbus used, the messages sent and received by the VLT
blocked by the firewall on the VLT
municate with the devices on the fieldbus. Therefore, ensure that the VLT
firewall on the VLT Servo Toolbox host system. Inappropriate changes to firewall settings may lead to security issues.
®
-
When using a dedicated network interface, the VLT
this network interface.

6.6.4.3 Indirect Communication

6.6.4.3.1 Overview
Communication between ISD 511 devices and the VLT
based fieldbus communication (marked A in the graphic) takes place between the PLC and the ISD 511 devices. However, there is
non-fieldbus communication between the PLC and the VLT
78 | Danfoss A/S © 2023.08
Description
For designing CAM profiles for the servo drives.
For setting up the motor and feedback parameters, and PID settings.
For motor inertia measurement.
Servo Toolbox functionality and the full parameter lists can be found in the VLT® Servo Drive
®
) Programming Guide.
™
Servo Toolbox installation file from the Danfoss website.
Servo Toolbox host system. This may lead to a loss of communication and the inability to com-
®
N O T I C E
®
Servo Toolbox through a PLC is called indirect communication. Ethernet-
®
6.6.2 System
Servo Toolbox is allowed to communicate through the
®
Servo Toolbox must be allowed to communicate specifically through
Servo Toolbox host system.
®
Commissioning
Requirements.
Servo Toolbox. There are 2 basic com-
®
Servo Toolbox may be
®
AQ377148425069en-000101 / 130R1213
