VLT® Servo Drive System ISD 511
Operating Guide
Description
3.9.3 LCP Cable
The LCP cable connects the LCP to the system modules via an M8 connector.
The LCP cable can be purchased from Danfoss (see the VLT® Servo Drive System ISD 510, DSD 510, MSD 510 (VLT® FlexMotion
Design Guide for further information and ordering numbers).
3.10 Local Control Panel (LCP)
3.10.1 Overview of the Local Control Panel
The LCP is the graphical user interface that can be connected to the PSM 510, DAM 510, and ACM 510 for diagnostic and operating
purposes using an optional cable (M8 to LCP D-SUB extension cable).
The LCP display provides the operator with a quick view of the state of the system module it is connected to. The display shows
parameters and alarms/errors and can be used for commissioning and troubleshooting. It can also be used to perform simple func-
tions, for example activating and deactivating the output lines on the DAM 510.
The LCP can be mounted on the front of the control cabinet and then connected to the system modules via SUB-D cables. The
maximum cable length is 3 m.
3.10.2 Layout of the Local Control Panel
The local control panel is divided into 4 functional groups:
•
A: Display area
•
B: Display menu keys
•
C: Navigation keys and indicator lights (LEDs)
•
D: Operation keys and reset
To adjust the display contrast, press [Status] and the [▵]/[▿] keys.
3.10.2.1 A: Display area
The values in the display area differ depending on which system module the LCP is connected to.
The display area is activated when the module it is connected to receives power from the mains supply, a DC bus terminal, or U
30 | Danfoss A/S © 2023.08
Maximum length
Cross-section
PE: 1 x 2.5 mm
System Description
Bending radius
2
AQ377148425069en-000101 / 130R1213
)
™
.
AUX
