VLT® Servo Drive System ISD 511
Operating Guide
Specification
Ambient temperature
Installation altitude
EMC standard for emission and immunity
EMC immunity functional safety
Pollution degree
Overvoltage category
11.8.2 System Modules
Table 137: General Specifications and Environmental Conditions for System Modules
Specification
Protection rating
Vibration test
Maximum relative humidity
Ambient temperature range
Installation altitude
EMC standard for emission and immunity
Danfoss A/S © 2023.08
Value
Operating: 5–45 °C
Storage/transport: –25 to +55 °C
Nominal current up to 1000 m above sea level.
Derating of output current (1% / 100 m) at 1000–3000 m.
Operation above 3000 m is not permitted.
EN 61800-3 (second environment)
EN 61800-5-2 Annex E
2
III
Value
IP20 according to IEC/EN 60529 (except connectors, which are IP00).
W A R N I N G
RISK OF ELECTRICAL SHOCK
The IP20 rating of the PSM 510, DAM 510, and ACM 510 modules is not fulfilled if
the modules are not connected to the backplate. This may result in death or seri-
ous injury.
-
Do not touch the backplate when a module is removed from the backplate.
Random vibration: 1.14 g (2h/axis according to EN 60068-2-64)
Sinusoidal vibration: 1.0 g (2h/axis according to EN 60068-2-6)
Storage/transport: 5–95% (non-condensing)
Stationary use: 5–93% (non-condensing)
Operating: 5–40 °C nominal, up to 55 °C with derating (see
Transport: –25 to +55 °C
Storage: –25 to +55 °C
Nominal current up to 1000 m above sea level.
Derating of output current (1% / 100 m) from 1000 m to 3000 m.
Operation above 3000 m is not permitted.
EN 61800-3 (second environment)
Specifications
Illustration 96)
AQ377148425069en-000101 / 130R1213 | 149
