VLT® Servo Drive System ISD 511
Operating Guide

4.5.3 System Modules

The environmental conditions for the PSM 510, DAM 510, and ACM 510 are:
• The allowable operating ambient temperature range, humidity, and vibration levels must not be exceeded (see
Modules).
• The minimum space required above and below the system modules is detailed in
ules.

4.6 Preparation for Installation

4.6.1 ISD 511 Servo Drive

Make the following preparations to ensure that the servo system can be installed reliably and effectively.
Always fit couplings and other transfer components in accordance with local regulations.
Procedure
1. Provide a suitable mounting arrangement for the application, taking into account the weight of the ISD 511 servo drive.
2.
Remove the protection cap on the flange.
3. Seat the motor flange flush against the mounting surface before fixing the servo drive. Misalignment shortens the life of
the bearings and the coupling components and reduces heat transfer from the servo drive. Ensure that the seal is not bum-
ped when inserting the drive into the machine as that could damage the seal resulting in impaired sealing function and
reduced service lifetime.
4.
Provide contact protection according to local regulations if hot surfaces can be expected during operation.
5. Ground the servo drive (see
4.6.2 System Modules
Make the following preparations to ensure that the servo system can be installed reliably and effectively.
Always fit the system modules in accordance with local regulations.
Procedure
1. Provide a suitable mounting arrangement for the application. This depends on the type and weight of the modules.
2. To avoid misalignment, ensure that the backplates are perfectly level.
3. To ensure sufficient cooling, pay attention to the specified minimum space requirements (see
System Modules).
4.
Ground the modules.
Danfoss A/S © 2023.08
5.3.1 Grounding the ISD 511 Servo
4.7.2 Space Requirements for System Mod-
Drive).
AQ377148425069en-000101 / 130R1213 | 35
Mechanical Installation
11.8.2 System
4.7.2 Space Requirements for
