5.9.3.2 Connecting the Feed-In Cable

4
Illustration 32: Connectors on the Bottom of DAM 510
1 Ethernet connector
2 AUX connector
1
26
Illustration 33: Feed-In Cable
1 Shielded area
2 UDC+ (black, 2.5 mm
3 UDC– (gray, 2.5 mm
4 STO+ (pink, 0.5 mm
5 STO– (gray, 0.5 mm
60 | Danfoss A/S © 2023.08
3 2 1
117
80
10
20
2
3
18 7
4
5
10
6
7
87
8
2
)
2
)
2
)
2
)
3 STO out connector
4 UDC connector
9
6 AUX+ (red, 2.5 mm
7 AUX– (blue, 2.5 mm
8 Ethernet/fieldbus (green, RJ45 connector)
9 PE (yellow/green, 2.5 mm
Electrical Installation
2
)
2
)
2
, fork lug)
