Danfoss VLT ISD 511 Operating Manual page 133

VLT® Servo Drive System ISD 511
Operating Guide
84.3
[3.32]
13 50 21.3
[0.51] [1.97] [0.84]
STATUS DAM
DEV
SVS ST
NET ST
AUX
LINK/ACT
X1
X2
X3
LCP
Illustration 73: Dimensions of DAM 510
11.3.5 Dimensions of Auxiliary Capacitors Module (ACM 510)
All dimensions are in mm [in].
Danfoss A/S © 2023.08
270
[10.63]
Specifications
25 25
[0.98] [0.98]
Ø5.2
[0.2]
Ø5.2
[0.2]
AQ377148425069en-000101 / 130R1213 | 133
