VLT® Servo Drive System ISD 511
Operating Guide
Certification Description
Part 1: General principles for design.
EN ISO 13849-2
Safety of machinery - Safety-related parts of control systems.
Part 2: Validation.
IEC/EN 60529 Degrees of protection provided by enclosures (IP Code).
UL 61800-5-1
Adjustable speed electrical power drive systems.
Part 5-1: Safety requirements - Electrical, thermal, and energy.
CSA C22.2 No. 274
Standard specifying requirements for adjustable speed drives with regard to electrical, thermal, and
energy safety considerations.
CE
2014/30/EU Electromagnetic Compatibility (EMC) Directive.
2014/35/EU Low Voltage Directive (LVD).
(2011/65/EU) amended Restriction of Hazardous Substances (RoHS).
(EU) 2015/863
2006/42/EC Machinery Directive (MD).
Ethernet POWERLINK Ethernet-based fieldbus system.
®
PLCopen Technical specification. Function blocks for motion control (formerly Part 1 and Part 2) Version 2.0
®
March 17, 2011.

1.5 Firmware Updates

For updates to the firmware, VLT

1.6 Terminology

Table 3: Terminology
Term Description
ACM 510 Auxiliary Capacitors Module
DAM 510
Decentral Access Module that connects the ISD 511 servo drives to the servo system via a hybrid cable.
EXM 510 Expansion module for splitting system modules between 2 control cabinets.
Feed-in cable Hybrid cable for connection from the DAM 510 to the 1st decentral drive.
ISD 511 Integrated Servo Drive
ISD 511 system compo- Includes ISD 511 servo drives, PSM 510, DAM 510, and the optional ACM 510 and EXM 510.
nents
LCP Local control panel
14 | Danfoss A/S © 2023.08
Servo Toolbox software and PLC libraries, contact Danfoss.
®
Introduction
AQ377148425069en-000101 / 130R1213
